WNS series gas fired industrial boiler prices
- QingDao TianJin ShangHai
- T/T L/C D/P D/A
You May Like
Product Details
| Condition | New | Type | Natural Circulation | |
| Usage | Industrial | Structure | Fire Tube | |
| Pressure | Low Pressure | Style | Horizontal | |
| Fuel | Gas-fired | Place of Origin | Shandong, China | |
| Brand Name | TONG HAI | Model Number | WNS | |
| Output | Steam | Dimension(L*W*H) | Customization | |
| Weight | Customziation | Certification | ISO CE ASME TUV | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Main Features:
1, Honor patented technology: 100% completely butt welding, mini stress and reliable quality.
2. Large diameter corrugated furnace: Combustion chamber is composed by large diameter full corrugation furnace, big combustion space.
3, High steam quality: Large steam space volume and enough height of the net distance between steam water interface and steam outlet.
4, Advanced automatic control: Boiler controller use Siemens/Delixi electrical element.
5, Multifunction safety explosion proof equipment: Boiler rear panel is equipped with explosion proof equipment which connected with furnace.
a.Boiler Rated output :0.5-100t/h
b.Boiler Rated steam pressure:0.7-7.5Mpa
c.Boiler Steam temperature:184-350degree
d.Boiler Thermal efficiency: ≥93 %
h.Apply fuel:light or heavy oil, natural gas or town gas, coke oven gas
k.Adjustment method: automatic
Technical specifications:
Item | Technical Specification | |||||||
Capacity: | 2t/h | 3t/h | 4t/h | 5t/h | 6t/h | 8t/h | 10t/h | 12t/h |
Rated steam pressure: | 1.0Mpa | 1.0Mpa | 1.0Mpa | 1.0Mpa | 1.25Mpa | 1.25Mpa | 1.25Mpa | 1.25Mpa |
Feed water temperature: | 20℃ | 20℃ | 20℃ | 20℃ | 105℃ | 105℃ | 105℃ | 105℃ |
Steam temperature: | 184℃ | 184℃ | 184℃ | 184℃ | 194℃ | 194℃ | 194℃ | 194℃ |
Fuel Type: | Natural gas, light diesel, heavy oil, LPG | |||||||
Efficiency: | Above 93% | |||||||
Boiler Weight: | 9649kg | 10457kg | 11840kg | 15220kg | 17976kg | 22657kg | 25720kg | 32000kg |
Boiler Size: | 2170*3750*2486mm | 2170*4810*2620mm | 2420*5110*2900mm | 2516*4900*3014mm | 2750*5660*3290mm | 2940*5760*3482mm | 2920*6630*3490mm | 3000*6820*3482mm |
The boiler for export:
working shop:
Germay SIMENS PLC control:
Movable doors for easy inspection & maintenance of boiler
Certificates:
1, Boiler body warranty 3 years.
2, Study the needs of customers, help customers decision.
3, Provide the completely design drawing and technical training service.
4, Supply all spare parts in boiler working life.
5, Installation and commissioning service.
How much steam capacity do you want ?
Answer: 0.5Ton/hr to 100Ton/hr
How much working pressure it the boiler ?
Answer: 4bar ~ 75bar
What kind of fuel do you prefer ?
Answer: L.P.G., Natural Gas, Light Diesel, Heavy Oil etc
what are the electric conditions in your market ? Voltage, HZ etc
Answer: 380V, 50HZ, 3Phase
Which burner our boiler use?
Answer: WEISHAUPT burner, RIELLO burner,UNIGAS burner,BALTUR burner.
