4E1+1ETH PDH Multiplexer
Negotiable
/ Set
2 Sets(Min. Order)
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | TINCAM | |
| Model Number | TBC-6240 |
Product Description
4E1+1ETH PDH Multiplexer
Product Description
*4E1 fiber optic converter
*E1 with BNC and RJ45
*One Ethernet available
*1310/1550nm option
*AC and DC power
TINCAM 4E1 fiber optic converteris a point to point fiber transmission device. It can realize 1~4E1 and one Ethernet over fiber. It's with full alarm monitor, high integration, low power consumption, stable performance and easy to use.
Main Features
- Single board design, 1U, 19inch
- Comply with ITU-T G.703, G823 and G.742
- Optical rate with 150Mbps
- Maximum one Ethernet ports available
- Ethernet auto adapts 10/100M, MDI/MDIX, full/half duplex
- One RS232 available for the transmission
- Full alarm indicators, easy to monitor the local and remote device status
- AC and DC dual power supply
Technical Specifications
Optical
- Default: dual fiber, single mode, 1310nm, 40km, FC
- Optical fiber type: dual fiber/single fiber optional
- Connector: FC/SC/ST
- Wavelength: 850nm/1310nm/1550nm
- Distance: 2km/40km/60km/120km
E1
- 1~4E1 available
- Comply with ITU-T G.703, G.823, G.742
- Rate: 2.048Mbps±50ppm
- Code: HDB3
- Connector: BNC for 75Ω, RJ45 for 120Ω
Ethernet
- Maximum 2 Ethernet available
- Connector: RJ45
- Frame length: 64kbps~1536kbps
- Auto adapt 10/100M, MDI/MDIX, full/half duplex
- MAC address table: 1024
Power
AC220V and DC-48V dual power supply
Environment
- Temperature: 0°C~50°C
- Humidity: 95%, non-condensing
