China Supplier Marine Fresh Water Generators With CCS
- shanghai
- T/T L/C Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | JG | |
| Model Number | CCFJ50JW | Output Type | AC Three Phase | |
| Speed | 1500rpm/1800rpm | Frequency | 50hz/60hz | |
| Rated Power | 50kw | Rated Voltage | 400v/440v | |
| Rated Current | 90A |
Product Description
Specifications
1.marine fresh water generators2.ISO,CE,CCS certificate
3.global service for 12 month
4.EIAPP(Nox)certificate
1. marine fresh water generators general feature:
Fengde Cummins series marine generator have features of compact structure, large power , low oil consumption , low discharge, low noise, reliable performances, and long services life .Its professional service networks are spread across the country and world , which can provide 24 hours after service and assure the supplying of accessories in time .
Feature:
Marine generator can use for Marine generator,
Marine emergency generator or Harbor generator
We use the marine synchronouse Alternator with the brands of Stamford , Maraphon and Simens marine Alternator etc. Also can be supplied at the request of customers.
Parallel connection: Two and more normal marine generating sets can transfer loading without stoping , and can realize parallel.
Protection function :Thare are over-limit alarming for speed , oil pressure, cooling water temperature and oil temperature.
Can provide CCS, BV , ABS,GL,RS, DNV classification certificate.
We are the top VIP supplier on Alibaba ,
authorized by famous certification authority-BV ( Bureau Veritas ).
2.50kw Marine Diesel Generator Technical Data:
50KW/63KVA Cummins marine diesel generating set
Engine model:6BT5.9-GM83
Alternator model:MP-H-50-4
1.Main technical data of gensets | ||
1.1 | Model | CCFJ50JW |
1.2 | Prime power | 50KW/63KVA |
1.3 | Prime voltage | 230/400V |
1.4 | Speed | 1500 rpm |
1.5 | Weight | 1100kg |
1.6 | Overall dimension | 1850×820×1350mm (just for reference) |
2.Main technical data of engine | ||
Cummins engine, 4 stroke. DC start. Come with sea water pump, heater exchanger and expansion water tank, open-cycle cooling. | ||
2.1 | Brand | CUMMINS |
2.2 | Model | 6BT5.9-GM83 |
2.3 | Prime power | 83KW/104KVA |
2.4 | Governor type | Electronic |
2.5 | Configuration | 4 cycle , 6 cylinder in line |
2.6 | Cooling method | By heater exchanger |
2.7 | Bore/Stroke | 102×120 mm |
2.8 | Displacement | 5.9 L |
2.9 | Starting method | Electric |
2.10 | Fuel consumption | 212g/kw.h |
3. Main technical data of alternator | ||
Alternator is selected the new type brushless alternator designed by US Marathon Electric, which has a unique design, advanced structure, small size, light weight, excellent performance, reliable running and easy-to-use operation. | ||
3.1 | Brand | MARATHON |
3.2 | Model | MP-H-50-4 |
3.3 | Prime power | 50KW |
3.4 | Configuration | Brushless , self-exciting |
3.5 | Prime voltage | 230V/400V |
3.6 | Frequency | 50 HZ |
3.7 | Power factor | 0.8(lagging) |
3.8 | Phase/wire | 3 phase 4 wires |
3.9 | Isolation | H |
3.Warranty
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4.Certificate & Document
a. Alternator operation and maintenance manual CCS certificate |
1PC 1PC |
b. Engine operation and maintenance manual CCS certificate EIAPPcertificate |
1PC 1PC 1PC |
c. Generator CCS certificate Overall drawings of the set ELECTRINIC SYSTEM DRAWING Bench test Packing list |
1PC 1PC 1PC 1PC 1PC |
d. Control panel CCS certificate operation and maintenance manual |
1PC 1PC |
