Good factory of slient quanchai diesel generator 50kva with ISO9000
US$ 4,999 - 5,999
/ Set
1 Set(Min. Order)
- FuZhou
- T/T
You May Like
-
Good factory of slient quanchai diesel generator 40kva with ISO9000
-
Good factory of quanchai diesel generator with cheap 30kva
-
Famous manufactur ! CE approved 25kva quanchai low price of generator with best service
-
Famous manufactur ! CE approved 18kva quanchai low price of generator for sale
-
Famous manufactur ! CE approved 15kva quanchai low price of generator for sale
-
Famous manufactur ! CE approved 12kva quanchai low price of generator
Product Details
| Place of Origin | Fujian, China | Brand Name | boomaster quanchai | |
| Model Number | BQ-50 | Output Type | AC Three Phase | |
| Speed | 1500/1800Rpm | Frequency | 50/60Hz | |
| Rated Power | 40Kw | Rated Voltage | 220V/380V 230V/400V | |
| Rated Current | 76A |
Product Description
Specifications
1.Rated power:10kva to 250kva2.Vol /Fre: 230/400V 50Hz
3.Power factor: 0.8
4.Silent
Good factory of slient quanchai diesel generator 50kva
with ISO9000
| Product Overview | |
| 1) Brand-new engine,w/start motor. | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. | |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
| 50Kva Quanchai diesel generator | |
| Genset Specification | |
| Genset Model | BQ-50 |
| Prime Power(Kw/Kva) | 40/50 |
| Frequency | 50Hz |
| Structure type | Open or Soudproof |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | 4JR3ACD |
| Alternator Model | STG224D |
| Open type DimensionL*W*H(mm) | 2100*850*1100 |
| Weight(Kg) | 1000 |
| Silent type DimensionL*W*H(mm) | 2300*1100*1300 |
| Weight(Kg) | 1100 |
| Engine Detail | |
| Manufacturer | Quanchai engine Co.,Ltd |
| Model | 4JR3ACD |
| Engine speed | 1500rpm |
| Engine power | |
| …………Prime power | 44KW(50Hz) |
| Type | vertical,4 cylinder,in-line,water-cooled,four-stroke |
| Aspiration | Naturally aspirated |
| Governor | electrical |
| Bore*Stroke | 105*135mm |
| Alternator Detail | |
| Model | STG224D |
| Output power(Kw/Kva) | 40/50 |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Number of Pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | 0.50% |
| Total haarmonics (TGH/THC) | 4% |
| Wave form:Nema=TIF | 50 |
| Wave form:I.E.C=THF | 2% |
| Bearing | single |
| Coupling | Direct |
Generator soundproof/Silent and canopy
Ø Excellent ventilation
Ø Black finish stainless steel locks and hinges
Ø Zinc plated or stainless steel fasteners
Ø Body made from steel components treated with polyester powder coating
Ø Two large doors on either side
Ø Radiator fill access plate
Ø Fully guarded cooling fan and battery charging alternator
Ø Fuel fill and battery access via lockable access doors
Ø Emergency stop button on canopy exterior
Ø Lube oil drain and radiator drain to exterior
Ø Control panel viewing window
Ø Lifting points on base frame
Ø 1m<80DBA / 7m<70DBA
Ø Do the full power load test for five hours before package.
Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
Ø After expiration, we provide spare parts maintenance
Quanchai Power Generator
Diesel engine
Factory
Exhibition
Certificate
Contact Us
- Elephant Tech Fuzhou Co., Ltd.
- Contact nameGT Wall Chat Now
- Phone86-0591-88371591
- AddressTieling Industry Area,Fuzhou,China, Fuzhou, Fujian
