80kva generator manufacturer in china(CCC,CE,BV,ISO9001)
- any chinese pport
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | Boomaster | |
| Model Number | BYC-80 | Output Type | AC Three Phase | |
| Speed | 1500/1800rpm | Frequency | 50/60Hz | |
| Rated Power | 80KVA | Rated Voltage | 230/400v, 120/208v | |
| Rated Current | 210A |
Product Description
Specifications
1.engine:yuchia2.Vol /Fre: 230/400V
3. Power factor: 0.8
4.Power:64kw/80kv a
5.one year warranty
Slient Generator,portable generator diesel,industrial generator
Generator Supply Scope:
Ø .Standrad tool kits and complete operation/maintenance/spare parts manuals to Engine/Alternator
Ø .brand-new engine, w/ start motor.
Ø .brand new brushless alternator, single bearing, flange connection, IP23, H insulation class, with AVR.
Ø .auto control panel, with LCD display.
Ø .Engine mounted battery-charging alternator, Genset with battery charger of mains supply.
Ø .Circuit Breaker,Exhaust Silencer
Ø .Copper Radiator for 50°C ambient temperature and bouble-deck cooling,with fan guard and front guard
Ø .Antivibration pads are fixed between engine/alternator and base frame,as to ensure the compete genset running under stablilization.
Ø .Skid-mounted bottom Fuel tank - 8hrs continous running(bigger fuel tank by your demand under extra cost)
Ø .External recessed emergency stop button for extra safety
Ø .The colors & Brands by your requests
Ø .Optional Choice:Soundproof, ATS (automatic transfer switch), AMF panel, Trailer, Parallel system by your extra choose.
Detail information
| Genset Specification | |
| Genset Model | BYC-80 |
| Prime Power(Kva/Kw) | 64KW/80KVA |
| Structure type | Open/Silent |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | YC6B135Z-D20 |
| Alternator Model | STG274C |
| DimensionL*W*H(mm) | |
| Open Type | 1982*850*1250 |
| Weight | 950 |
| Silent Type | 2082*950*1350 |
| Weight(Kg) | 1000 |
| Engine Detail | |
| Engine Brand | Yuchai Diesel engine |
| Model | YC6B135Z-D20 |
| Engine speed | 1500rpm |
| Engine power | |
| …………Standby power | 99KW |
| …………Prime power | 90KW |
| Type | 6cycle,in-line,6-cylinder |
| Aspiration | Turbocharged, |
| Governor | electrical |
| Bore*Stroke | 108*115mm |
| Displacement | 4.214 Litres |
| Compression ratio | 17.5:1 |
| Alternator Detail | |
| Manufacturer | Fuzhou Boomaster Power Co.,Ltd |
| Model | STG274C |
| Output power | 80KVA |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Altitude | ≤1000m |
| Overspeed | 2250rpm |
| Number of Pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | ±0.5% |
| Sustained short circuit current | 300%(3IN):10s |
| Total haarmonics (TGH/THC) | <4% |
| Wave form:Nema=TIF | <50 |
| Wave form:I.E.C=THF | <2% |
| Bearing | single |
| Coupling | Direct |
Generator set warranty and maintenance:
Ø Do the full power load test for five hours before package.
Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
Ø After expiration, we provide spare parts maintenance with low price.
Other pictures:
Silent diesel generator
Our factory
Certification
