Home > Products > Power by Yuchai > yuchai diesel generator 50kva slient with CE/ISO9000/BV
yuchai diesel generator 50kva slient with CE/ISO9000/BV
You May Like
-
40kva Single & Three Phase Petrol Diesel Silent and open Generator
-
250kw electric diesel generator
-
80kva generator manufacturer in china(CCC,CE,BV,ISO9001)
-
China Brand 50 kw Silent Self Powered Electric Generators
-
50 kva generator silent diesel,generator with Chinese engine
-
40kva generators for home with prices
Product Details
| Place of Origin | Fujian, China | Brand Name | Boomaster yuchai | |
| Model Number | DG-50S | Output Type | AC Three Phase | |
| Speed | 1500/1800rpm | Frequency | 50Hz | |
| Rated Power | 50KVA | Rated Voltage | 220v/380v 230v/400v | |
| Rated Current | 76A |
Product Description
Specifications
yuchai diesel generator 50kva slient with CE/ISO9000/BV1 .Vol /Fre: 230/400V 50Hz
2.Power factor: 0.8
3.slient
yuchai diesel generator 50kva slient with CE/ISO9000/BV
| Product Overview | |
| 1) Brand-new engine,w/start motor. | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. | |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
| Genset Specification | |
| Genset Model | BYC-50 |
| Prime Power(Kva/Kw) | 40KW/50KVA |
| Structure type | Open/Silent |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | YC4D85Z-D20 |
| Alternator Model | STG224D |
| DimensionL*W*H(mm) | |
| Open Type | 1982*850*1250 |
| Weight | 920 |
| Silent Type | 2082*950*1350 |
| Weight(Kg) | 1070 |
| Engine Detail | |
| Engine Brand | Yuchai Diesel engine |
| Model | YC4D85Z-D20 |
| Engine speed | 1500rpm |
| Engine power | |
| …………Standby power | 44KW |
| …………Prime power | 40KW |
| Type | 4cycle,in-line,4-cylinder |
| Aspiration | Turbocharged, |
| Governor | electrical |
| Bore*Stroke | 108*115mm |
| Displacement | 4.214 Litres |
| Compression ratio | 17.5:1 |
| Alternator Detail | |
| Manufacturer | Fuzhou Boomaster Power Co.,Ltd |
| Model | STG224D |
| Output power | 40KW |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Altitude | ≤1000m |
| Overspeed | 2250rpm |
| Number of Pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | ±0.5% |
| Sustained short circuit current | 300%(3IN):10s |
| Total haarmonics (TGH/THC) | <4% |
| Wave form:Nema=TIF | <50 |
| Wave form:I.E.C=THF | <2% |
| Bearing | single |
| Coupling | Direct |
Generator soundproof/Silent and canopy
Ø Excellent ventilation
Ø Black finish stainless steel locks and hinges
Ø Zinc plated or stainless steel fasteners
Ø Body made from steel components treated with polyester powder coating
Ø Two large doors on either side
Ø Radiator fill access plate
Ø Fully guarded cooling fan and battery charging alternator
Ø Fuel fill and battery access via lockable access doors
Ø Emergency stop button on canopy exterior
Ø Lube oil drain and radiator drain to exterior
Ø Control panel viewing window
Ø Lifting points on base frame
Ø 1m<80DBA / 7m<70DBA
Generator set warranty and maintenance:
Ø Do the full power load test for five hours before package.
Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
Ø After expiration, we provide spare parts maintenance with low price
Slient yuchai power generator
Stamford alternator of generator
Controller
Factory
Exhibition
Certificate
