Cummins Engine 125kva Diesel Generator Set

FOB Price

US$ 10,299 - 10,755 / Set

1 Set(Min. Order)

Port Fuzhou.China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	Boomster cummins engine
Model Number	BMC series cummins engine 125kva diesel generator set	Output Type	AC Three Phase
Speed	1500/1800RPM	Frequency	50HZ/60HZ
Rated Power	125kva	Rated Voltage	110V/240V, 220V / 380V, 230V/400V, 240V/415V

Product Description

Cummins engine 125kva diesel generator set with CE ISO EPA

Technical Data
Genset Model	TC330
Prime Power	300KVA/240KW
Standby Power	330KVA/265KW
Rated Voltage	400/230V
Frequency	50Hz
Radiator	50°C max with coolant cap
Charge Alternator	24V
Dimension(LWH) (mm)	3000×1100×1900
Net Weight (kg)	3201
Diesel Engine
Brand			Cummins
Model			NTA855-G1A
Governor Type			Electrical
Rotating Speed			1500 rpm
Engine Cooling Method			Water-cooled
Displacement(L)			14
Bore×Stroke(mm)			140×152
Alternator
Brand		Stamford
Model		HCI444D
Power Factor(COS Phi)		0.8
Excite Type		Brushless SHUNT
Connecting Type		3 Phase & 4 Wires
Insulation Degree		H/H
Enclosure Degree		IP23

1) Brand-new engine,w/start motor.

2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.

3) Auto control panel with LCD display.

4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.

5) Circuit Breaker,Exhaust Silencer.

6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard.

7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.

8) Skid-mounted bottom 8 hours fuel tank.

9) Extemal recessed emergency stop button for extra safety.

10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.

Guaranty:

Guarantee for one year or 1000 hours (whichever comes first) from ex-factory date. During the guarantee period, our Boomaster will provide the free easy-damaged spare parts for problems caused by our quality of production or raw materials,

except the damage caused by customer's incorrect manmade operation.

After expiration, our company will provides cost spare parts maintenance for genset

MOQ	1 set
Delivery Clause	FOB Fuzhou
Terms of payment	T/T, L/C at sight

.Leading Professional manufacturer of power generator

.Certification:CE EPA ISO IEC

.Fast delivery:we will do our best to meet your requirement when you need it.

.Product quality :Famous high quality engine.we offer spare parts.

.OEM is warmly welcomed
