JY-E50 Large Flow Light Diesel Particle Filter for Oil Drums With Polymer Membrane Filtration Technology

JY-E50 Large flow light diesel particle filter for oil drums

                              with  polymer membrane filtration technology

Excellent Performance:

Polymer membrane filtration technology

Can be used as by-pass filter

 Oil-water separation efficiency is more than 95%

 Precision can be controlled from 2~25 micron

Selectivity-pass characteristic of 3D pore structure filter

High interception rate and low filtration cost

 Customized service provided according to filtration requirements

 Filter elements can be used repeatedly after back-washed

Design service life is more than 20 years (except for filter elements)

Technical Parameters:

1.Model Type: JY-E50

2.Flow Rate: 40 L/min

3.Filtration System: (1)Polymer Membrane Filter Elements (Can be used repeatedly after washing)

J22-401L------------------------------------------------------------10μm

J22-401H------------------------------------------------------------5μm

(2)Filter Element Quantity: 68 Pieces

 (3)Function: Remove impurity particles, colloid and water

(4)Working Pressure: 0.2~0.35 Mpa

(5)Filtration Level: 2 (6)Service life: 2~3 Years or longer

 4.Filtration Precision: (1)Range: 2,5,10,15,25 μm (2)Standard: 5~10 μm

 5.Mouth: Standard: DN20 or According to Requirements

 6.Security: With Pressure Safety Valve

7.Temperature: Working Temperature: -10~70 ºC

 8. Dimension: 550*560*920mm

 9.Weight: 77KG

10.Anti-hazard Classification: Grade 2

11.Power System: (1)Electric Motor:HONDA  5.5HP Engine (2)Pump: Diesel Pump/ Gear Pump ( Depend on oils)

Advantage:

1. Low MOQ: It can meet your promotional business very well.

2. OEM Accepted: We can produce any your design.

3. Good Service: We treat clients as friend.

4. Good Quality: We have strict quality control system .Good reputation in the market.

5. Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
