Guide Rail Fishplate
Negotiable
/ Ton
20 Tons(Min. Order)
- Zhangjiagang port
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Banda | |
| Model Number | BD-01 |
Product Description
Guide Rail Fishplate
1.Material: Q235A.
2.Various thickness, other thickness on request.
3.Meet ISO7465 standard.
Fishplate, Elevator guide rail fishplate,Guide Rail Fishplate
Banda has been mainly supplying high quality elevator fishplate according to customers' request as follows.
1 Specification: Fishplate for machined guide rails, cold drawn rails and hollow guide rails.
2 Main dimensions:
Guide Rail Fishplate Drawing:
Guide Rail Fisplate Specification:
| Type | d | b2 | b3 | l1 | l2 | l3 | v |
| Tolerance | ±1.5 | ±0.2 | ±1.5 | ±0.2 | ±0.2 | -0/+2 | |
| T45/A | 9 | 50 | 25 | 160 | 65 | 15 | 8 |
| T50/A | 9 | 50 | 30 | 200 | 75 | 25 | 8 |
| T70-1/B | 13 | 70 | 42 | 250 | 105 | 25 | 8.5 |
| T75-3/B | 13 | 75 | 43 | 240 | 90 | 30 | 10 |
| T78/B | 13 | 90 | 43 | 240 | 90 | 30 | 10 |
| T89/B | 13 | 90 | 57.2 | 305 | 114.3 | 38.1 | 13 |
| T90/B | 13 | 90 | 57.2 | 305 | 114.3 | 38.1 | 13 |
| T114/B | 17 | 115 | 74 | 305 | 114.3 | 38.1 | 17 |
| T127-1/B | 17 | 130 | 79.4 | 305 | 114.3 | 38.1 | 17 |
| T127-2/B | 17 | 130 | 79.4 | 305 | 114.3 | 38.1 | 17 |
| T140-1/B | 21 | 140 | 92.1 | 380 | 152.4 | 31.8 | 25 |
| T140-2/B | 21 | 140 | 92.1 | 380 | 152.4 | 31.8 | 25 |
| T140-3/B | 21 | 140 | 92.1 | 380 | 152.4 | 31.8 | 30 |
Guide Rail Fishplate Packing:
