Home > Products > Product Showcase > VM1580 Vertical used cnc milling machine for Sale
VM1580 Vertical used cnc milling machine for Sale
- 10 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Liaoning, China | Brand Name | R&C | |
| Model Number | VM1580 | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
VM1580 Vertical used cnc milling machine for Sale
Specification And Data | ||||||
Item | VM1060 | VM1265 | VM1370 | VM1580 | Unit | |
Travel | X axis travel | 1000 | 1200 | 1300 | 1500 | mm |
Y axis travel | 600 | 700 | 700 | 800 | mm | |
Z axis travel | 600 | 600 | 650 | 700 | mm | |
Distance from spindle nose to table surface | 180-780 | 150-750 | 150-800 | 170-870 | mm | |
Table | Size | 600×1300 | 700×1360 | 710×1400 | 800×1700 | mm |
T-slots | 22×5 | 22×5 | 22×5 | 22×5 | mm | |
Max. loading capacity | 800 | 1000 | 1000 | 1500 | kg | |
Spindle | Spindle taper | BT40 | BT50 | BT50 | BT50 |
|
Spindle speed | 8000 | 8000 | 6000 | 6000 | rpm | |
Spindle motor power | 7.5/11 | 7.5/11 | 7.5/11 | 11/15 | kw | |
Spindle unit | TAIWAN | TAIWAN | TAIWAN | TAIWAN |
| |
Spindle diameter | 180 | 180 | 180 | 180 | mm | |
Feed rate | Rapid traverse | 24000 | 24000 | 20000 | 12000 | mm/min |
Feed rate | 4000 | 4000 | 4000 | 4000 | mm/min | |
Motor | Axis motor X/Y/Z | 4.4 | 4.4 | 4.4 | 4.4 | kw |
Coolant pump motor | 150 | 150 | 150 | 150 | W | |
Accuracy | Repeatability | 0.005 | 0.005 | 0.005 | 0.005 | mm |
Positioning accuracy | 0.01 | 0.01 | 0.01 | 0.01 | mm | |
Others | Ball screws | HIWIN | HIWIN | HIWIN | HIWIN |
|
| Spindle unit | Taiwan | Taiwan | Taiwan | Taiwan |
|
| Coupling | KTR | KTR | KTR | KTR |
|
| Lubrication system | Auto | Auto | Auto | Auto |
|
| Coolant tank capacity | 150 | 150 | 150 | 150 | L |
| CNC system | SIEMENS 828D/ | SIEMENS 828D/ | SIEMENS 828D/ | SIEMENS 828D/ |
|
| Spindle cooling system | standard | standard | standard | standard |
|
Welcome to contact us.
