Anytone AT-5555 CB Radio 25.615-30.105mhz
- XIAMEN/SHENZHEN
- T/T Credit Card
You May Like
Product Details
| Model Number | AT-5555 | Brand Name | ANYTONE | |
Product Description
10Meter Radio/Citizen Band Radio
1.CE&RoHS approval
2.Mode:AM,FM,USB,LSB,PA,CW
3.Large LCD display
4.Frequency programmable on computer.
5.ASQ function
6.SSB radio
AT-5555 specification
General | |
Frequency Range | 25.615MHZ—30.105MHZ (Programmable) |
Frequency Band | A/B/C/D/E/F |
Channel | 60 channels (programmable) in each band |
Frequency Control | Phase-Locked-Loop Synthesizer |
Frequency Step | 10Hz 100Hz 1KHz 10KHz |
Frequency Tolerance | 0.005% |
Frequency Stability | 0.001% |
Temperature Range | -30°Cto +50°C |
Microphone | Plug-in dynamic; with push-to-talk /UP/DN/ ASQ switch and coiled cord |
Input Voltage | DC 13.8V normal, 15.9V max; 11.7V min Transmit: AM full mod 5A Receiver: Squelched 0.6A SSB 21W PEP output 6A |
Size | 28*25*6CM |
Weight | 2.8KG |
Antenna Connector | UHF,SO239 |
TRANSMITTER | |
Power Output | AM/FM/CW: 12W SSB:21W(PEP) |
Modulation | High and low level class B Amplitude Modulation: AM Varied Capacitance Frequency Modulation: FM |
Inter-modulation Distortion | SSB: 3rd order, more than -25dB; 5th order, more than -35dB |
SSB Carrier Suppression | 55dB |
Unwanted Sideband | 50dB |
Frequency Response | AM and FM: 450 to 2500HZ |
Saida Impedancia | 50ohms, unbalanced |
Sensitivity | SSB: 0.25μV for 10dB(S+N)/N at greater than 1/2-watt of audio output. AM:1.0μV for 10 dB(S+N)/N at greater than 1/2watt of audio output. FM: 1.0 μV for 20 dB (S+N)/N at greater than 1/2 watt of audio output. |
Selectivity | AM/FM:6dB 3KHz,50dB 9KHz SSB: 6 dB 2.1KHz,60dB 3.3KHz |
Image Rejection | More than 65dB |
IF Frequency | AM/FM: 10.695 MHz 1st IF, 455 KHz 2nd IF SSB: 10.695 MHz |
Adjacent-Channel | 60dB AM/FM &70 dB SSB |
Rejection |
|
RF Gain Control | 45 dB adjustable for optimum signal reception |
Automatic Gain Control(AGC) | Less than 10 dB change in audio output for inputs from 10 to 100,000 microvolt. |
Squelch | Adjustable; threshold less than 0.5 μV. Automatic Squelch Control(only AM/FM) 0.5 μV |
ANL | Switchable |
Noise Blanker | RF type, effective on AM/FM and SSB |
Audio Output Power | 4 watts into 8 ohms |
Frequency Response | 300 to 2800 Hz |
Built-in Speaker | 8 ohms, round. |
External Speaker(Not Supplied) | 8 ohms; disables internal speaker when connected.
|
Qixiang Electron Science & Technology Co., Ltd, founded in 1993, ,Covers an area of 18 acres, has built 25000m2 standardized Garden-plant building ,is a high-tech enterprise specialized in developing, producing and selling wireless communication equipment, such as Transceiver, Mobile transceiver,Cell-phone Repeater, Marine professional communication systems, wireless communications equipment.
Our products are exported to more than 30 countries,The company's own brand ANYTONE was registered in China, United States, Europe.In Russia, Taiwan registered admissibility . Anytone brand warmly welcome and popular in oversea market,Importer and distributor for Anytone all over the world .ANYTONE brand awards as Fujian famous trademark,Qixiang was established distributors more than 20 provinces in China;and has a number of independent intellectual property rights in scientific research,Has much technology patents and software copyrights, received the ISO9001 and ISO14001 certificates ,Products got the approval of the Ministry of Information Industry of the People's Republic of China,Most of products with CE,FCC and ROHS approval.
