Home > Products > DC motor with gearbox > 24V 250WDC Mirco Gear Motor,spur Gear Reduce Motor,
24V 250WDC Mirco Gear Motor,spur Gear Reduce Motor,
US$ 16.54 - 125.3
/ Piece
1 Piece(Min. Order)
- Ningbo
- T/T Credit Card
You May Like
-
RV Series Flange Mounted Worm Gear Reducer With Competitive Price
-
NRV Series Hollow Shaft Worm Reduction Gearbox
-
NMRV+NMRV Double Stage Worm Gear Speed Reducer With High Quality
-
China Manufacturer NMRV+NMRV Double Stage China Gear Reducer
-
NMRV+NMRV Worm Gearbox Hollow Shaft
-
China Manufacturer High Quality NMRV Mini Worm Gear Reducer
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Hengbai | |
| Model Number | 90ZYT196-250 | Usage | Car, Home Appliance, Other | |
| Certification | CCC, CE | Type | Gear Motor | |
| Torque | High Torque | Construction | Permanent Magnet | |
| Commutation | Brush | Protect Feature | Totally Enclosed | |
| Speed(RPM) | 3000rpm | Continuous Current(A) | 13.5A | |
| Output Power | 250W | Voltage(V) | 24V | |
| Efficiency | IE 2 |
Product Description
geared motor power range is from 6W-3.7KW(1/125hp to 5hp) ,the speed ratio is from 1:3 to 1:3000,output speed from 0.5rpm-500rpm
Motor :90ZYT196
Gearbox: 5GN15k
speed: 1rpm to 500rpm
DC motors of 24V and 12V available. speed 1800rpm
We are professional Geared motor facotry located in China.
Our geared motor power range is from 6W-3.7KW(1/125hp to 5hp) ,the speed ratio is from 1:3 to 1:3000,output speed from 0.5rpm-500rpm,110V-120V,220V-240V,380V-415V all can be made.Special motors also can be designed and manufactured.
motor Specifications
| type | torque | votlage | speed | working time | weight | ||
| 90ZYT196 | 3.2 | 12v | 60 | continuous | 7.8kg | ||
| 24v | |||||||
| 90v | |||||||
| 6.0 | 12v | 72 | continuous | 8kg | |||
| 24v | |||||||
| 90v |
