Steel Structure Sandwich Panel Prefabricated Homes Container House

Item Name

Container house

Main Material

Q235/Q345 Welded H Beam and Hot Rolled Section Steel

Surface

Painted or Hot Dip Galvanized

Roof& Wall Panel

EPS Sandwich panel /Single Corrugated Steel Sheet/ Color sheet with Glass-wool, for customers choose

Window

PVC Steel or Aluminum Alloy

Door

Sliding Door or Rolling Up Door

Service

Design, Fabrication and Installation

We can make quotation according to customer's drawing or requirement; (size by length/width/height and wind speed), offering a free design drawing and all detailed drawings for installation.

Packing

According to customer's requirement

Name

Type

Material

Size

Wall Panel

1.Wall panel with steel sheet on both external and internal sides

2. Wall panel with steel sheet on external side and chipboard on internal side

1.Mineral Wool

2.PU

Width:1145mm

Thickness : Customize

(rang from 60mm to

100mm)

Door

1.Steel Door

2.Aluminum Door

3.Aluminum Alloy Door

4.PVC Door

5.Fireproof Door

1.Honeycomb Paperboard

2.Mineral Wool

3.PU

Ordinary Size:

950*1995mm

870*2040

Customize

Window

1.Sliding Window

2.Tilt & Turn Window

1.PVC

2.Aluminum Alloy

Ordinary Size:

945 x 1,200 mm

800 x 1,100 mm

Customize

Electrical Installation

Switch and Socket

1. CE Standard

2. Australia Standard

3. UL Standard

Electrical Circuit

The bottom

Frame made of Q235 steel board,

seamless bended,

seamless welded,

surface galvanized.

Painted with anti-corrosive paints, laying materials: laminate board, PVC board, block board, cement fiber board etc.

Bottom serial

1. Standard laminate floor

2. Public Toilet bottom

3. Bottom of the toilet in the middle

4. Standard PVC bottom

5. Light steel keel bottom

The wall system

Consists of 0.42mm colored steel sheets on both sides or one 0.42 colored sheet and one 0.42mm stainless sheet, integrated with PUEPSROCK WOOL etc.

The size of the wall is 2310mm*1158mm.

The thickness of the external wall is 75mm, and the internal wall is 50mm.

The density of the EPS is 12kgm³, the density of the rock wool is 100kgm³.

And the color of the wall is as per the clients’ demands.

Wall system series

1. Standard wood pattern wall panel

2. Standard blue wall panel

3. Inner door standard wall panel

4. External door(steel security door)fitted with standard yellow wall panel

5. External door(steel security door)fitted with standard block pattern wall panel

6. External door(steel security door)fitted with standard blue wall panel

7. Window(PVC aluminium alloy window) fitted in the standard wall panel) size:800*1,100mm

8. Window(PVC aluminium alloy window) fitted in the standard wooden pattern wall panel) size:800*1,100mm

9. Bathroom ventilated window(PVC aluminium alloy window) together with exhaust fan being fitted in the wall panel. Size: 800*400mm

Accessories

Decoration strip,

skirting line,

 inner corner,

inner corner pedestal,

corner parts,

 plastic seaming rib,

wall panel fixer, socket, switch,

security door lock,

stairway bracket connection,

 Laminate floor
