Pultrusion Durable Fiberglass Tool Handle

carton box.

Specifications

Pultrusion Durable Fiberglass Tool Handle

Fiberglass pole, fiberglass rod ,fiberglass tube , fiberglass profiles, FRP pole,FRP rod, FRP tube.

1.Brief introduction of Sanchuang Factory

Dongguan Sanchuang FRP Products Factory is a research and development , production and sale of composite technology enterprises . The main products include the fiberglass and carbon fiber pultrusion profile , SMC/BMC/DMC molding products, RTM products, winding molding pipe and high-quality hand lay-up products,widely used in construction,electricity, communication,transportation, light industry, petrochemical engineering , ocean industry,mechatronik, sport and relaxation,agriculture and so on.

2.Physical Parameters of FRP Products

Mechanical performance

Tensile Strength: LW260-600MPa  CW45-80 MPa; Test Method: ASTM D-638.

Tensile Modulus:LW18-30Gpa CW7-13Gpa; Test Method: ASTM D-638.

Flexural Strength:LW300-700Mpa,CW80-120Mpa, Test Method:ASTM D-790.

Flexural Modulus:LW20-26GPa,CW7-12GPa, Test Method:ASTM D-790.

Compressive modulus:LW280 Mpa CW105Mpa,Test Method:ASTM D-695.

Interlayer Shear Strength:LW 25 Mpa, Test Method:ASTM D-2344.

Impact Strength: 280 KJ/M²,Test Method:ASTM D-256.

Physical Property

Barcol Hardness: 50 Test method:ASTM D-495

Water absorption(25°c,24h):0.2-0.5%,Test method ASTM D-570.

Density:1.75-2.00 g/cm³, Test  method ASTM D-570.

Coefficient of thermal expansion(LW) 5.0 10^-6/ °c ,  Test method  ASTM D-696.

Coefficient of thermal conductivity 0.4  W/(M.K)   ,Test method ASTM C-518.

Elongation to break 0.9%,   Test Method  ASTM D-638.

Electrical property

Arc resistance (LW) 120 seconds,Test method ASTM D-495.

Dielectric constant (PF)5@60hz, Test method ASTM  D-150.

Dielectric strength (PF) 8KV/mm Test method ASTM D-149.

Surface resistance:10¹⁵-10¹² Test method ASTM D-257.

Volume restistance:10¹⁵-10¹² Test method ASTM D-257.

Flammability property

Tunnel test :Max25  25-28  second, Test method ASTM E-4.

Oxygen data 28-32 >32 % Test method ASTM 2863.

Flammability classification Self extinguish , Test method:ASTM D635.

Notes:LW-lengthwise , CW-crosswise. PE=perpendicular to laminate face.

 3.Fibergals composite profile Feature:

 Fibergalss composite profile  with a surface veil and inhibitor , all the pultruded profile  can protect glass fibers from pentrating the resin and can also increase the corrosion and UV resistance . These profile are non-magnetic and have good electrical and thermal insulation properties. Our FRP profile are stronger than Aluminum in the lengthwise direction of the profile . These profile can be easily fabricated with carpentry or metal working tools , fasten with screws , bolts and rivets or jointed we adhesies.

4.Sanchuang ISO Certificate:

 Any more detail , please feel free to contact with Nina.
