RECI cheap CO2 laser cutting machine power supply 24v 100w for sale

100W 24V Co2 Laser Machine Power Supply

Features

1. The performance is stable, each power supply are through strict selection (main parts are imported from), and multiple testing, low temperature experiment, with high temperature aging.

2. Good compatibility: adapt to many manufacturers from the type of CO2 laser tube sealing (100 ~ 120 w).

3. Fast response speed, engraving, cutting effect is good, and the laser is prolonged.

4. Control is simple: can choose high or low level control, using TTL level control of the laser, stop. Laser power control is simple and can be used to 0 ~ 5 v analog signals control the size of the laser power, you can also use controlled PWM (pulse width modulation) signals.

5. Protection function: power itself has protection switch, check whether external drainage systems, ventilation, etc. Under the condition of the protective ear thing good, power can short time to work on open circuit state. Which avoids the laser tube burst caused damage to the laser power supply.

6. Special functions: (optional) the user does not need to disconnect the power supply enclosure, you can simply laser power supply is working correctly; so as to distinguish the laser tube is failure, or power failure.

7. Areas of application: handicraft, acrylic, leather, cloth, rubber version of the material such as sculpture, cutting, etc.

Technical parameters

1. Input as the input voltage: AC220V or AC110V (when ordering specify) ac frequency: 47-440 hz cold surge current: 60 a (AC220V input) or less 30 or less a leakage current (AC110V input) : 0.7 mA (AC220V input) or less 0.4 mA (AC110V input) or less.

2. Maximum output current output maximum output voltage: DC40KV: DC28Ma.

3. Efficiency of 90% or more (full).

4. The response speed of 1 ms or less (from switch signal to the output current up to 90% of the time set current).

5. Control interface TTL level switch testing, choice of effective level can be high or low (see instructions).

6. Compared to high voltage input AC1500V, 50 hz, leakage current is less than 10 ma, breakdown in 60 seconds..

7. Insulation impedance DC500V, 50 or more Μ Ω.

8. Protection can be short-term open circuit (power supply enclosure grounding is good, at the same time avoid arc) between the positive and casing.

9. Using the environment temperature: - 10 ℃ to 50 ℃, storage temperature: - 20 ℃ ~ 75 ℃, relative humidity: 90% RH (not curdle).

10. Forced air cooling way.

11. Shape size L * W * H = 285 * 190 * 285 (mm).
