SATA III NGFF slot PCI-e Card SATA 6Gbps 3.0 HDD M.2 SSD to PCI Express card Quality Choice

FOB Price

USD $5.95 - $7.95 / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock		Brand Name	PANTO
Model Number	PT-LM-412N		Place of Origin	Guangdong, China

Product Description

SATA III NGFF slot PCI-e Card SATA 6Gbps 3.0 HDD M.2 SSD to PCI Express card

Item.	PT-LM-412N
Item.	PT-LM-412N
Warranty Information
Warranty	2 Years
Hardware
Ports	3
Interface	2 X NGFF + 1 X SATA
Bus Type	PCI Express X 4
Card Type	Standard Profile (LP bracket optional )
Port Style	Integrated on Card
Industry Standards	SATA 3.0 specification for B key
	PCI Express M.2 specification 1.0.
	PCI-E 4X 3.0 specification for M key
	M.2 Specification Revision 0.9
Chipset ID	N/A
Connector(s)
Connector Type(s)	1 - PCI Express x4 Male
Input Ports	1 - pcie x4 or Sata3.0
Output Ports	2-expand two port female NGFF(M.2) solt Key M & Key B
Performance
Maximum Cable Length	19.6 ft [50 cm]
Maximum Data Transfer Rate	6 Gbps
Type and Rate	SATA 3.0 - 6 Gbit/s
UASP Support	Yes
SSD Support	2230, 2242, 2260 & 2280 size NGFF SSD
SSD Support	Suitable for intel 7260NGW with 802.11ac WiFi & Bluetooth 4.0
Software
OS Compatibility	Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64)
	Windows Server® 2012, 2008 R2, 2003
	Linux 2.6.31 or later
Special Notes / Requirements
System and Cable Requirements	Available PCI Express slot
Note	--For B key SSD the SATA 7 pin connector must be connected to motherboard. --For M key SSD there must be a 2.0 or higher PCI-E 4X socket
Physical Characteristics
Product Length	4.7 in [121 mm]
Product Width	3.9 in [100 mm]
Product Height	0.9 in [23 mm]
Product Weight	1.8 oz [51 g]
Environmental
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	5~85% RH
Packaging Information
Shipping (Package) Weight	5.4 oz [153 g]
What's in the Box
Included in Package	1 -PCIE X4 to NGFF(M.2) SSD+SATA to NGFF(M.2)adapter card
	1 -Screw Drive
	1- Screw Pack
	1 - Sata cable

x4 PCIe to SATA 3.0 + NGFF(m.2) RAID Card HyperDuo SATA port multiplier 88SE9230 SATA3.0

Our Company

We have our own factory, R&D team, professional engineers and production lines. Our teams are good at designing and developing newest IT products with advanced software,like AutoCAD,Pro/E,Protel99,PADS,CorlDRAW. We have acquired the CE, FCC certification and compliant with the RoHS. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to listen and discuss your requirements and ensure full customer satisfaction. In recent years, our company has introduced a series of advanced equipment, research and develop many new products for your more and more wide application.Our products are exported to all over the world, mainly North and South Amercia, Europe, East Asia especially Japan, and earned good reputation in both domestic and overseas market.OEM and ODM are available,small quantity are acceptable.

Certifications

Packing & Delivery

Packing

packing detials

* Standar Exported Master Carton Package

* Master Carton Size 25*25*25CM Net Weight: 2.5KG, Gross Weight: 3KG

* Plastic Pallet Size: 80X120X100CM 1920PCS/48Cartons/Pallet, Gross Weight:120KG

Delivery

Our Service

-- We are the factory manufacturer so we can offer you with quite nice factory price.

-- Our products are all in good quality with nice appearance.

-- All of our products are brand new

-- All our products are packed carefully to ensure it is intact when you receive it.

--OEM is available and are welcomed. You can request to print your logo or other things on the product by paying us small amount of money.

-- Any questions about us and our products are welcomed. We will answer you with patience.

--Please kind contact us any time via

WhatsApp/Mobile:+8613266805354 SKYPE: fld-qy E-mail: andylee#
