Home > Products > LCD Video Wall > 46inch 450nits 6.7mm bezel HD Samsung LCD Video Wall
46inch 450nits 6.7mm bezel HD Samsung LCD Video Wall
- 50000 Set / Sets per Month
- SHENZHEN
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | USER | |
| Model Number | US-LTI460AA05 |
Product Description
Specifications
1,46",6.7mm Super narrow bezel2,HD1366x768 resolution
3,450nits brightness
4,2000:1contrast
5,Rich interface,multi function
Descriptions
US-LTI460AA05 is a color active activation liquid crystal display (LCD) that displays use of non-crystalline silicon TFT (Thin Film Transistor) as switching components. This mode of display, mainly by a TFT LCD panel, a driver circuit and a backlight unit. One with a 46.0 inches display, a resolution of 1366x768, and this mode of display can show up as high as 16.7 million kinds of colors, these colors with wide viewing angle in the display, but in all directions is equal to or greater than 89c. This display panel applied to support a variety of occasions, so it can provide excellent display performance, for example, can be used in home multimedia TFT-LCD TV in the flat-panel displays, AV audio-visual products, display terminals, and digital information display(DID).
Specifications
| Model No. | US-LTI460AA05 |
| Screen size | 46'' Samsung DID LCD screen(with narrow bezel 6.7mm) |
| Display area(mm)/mode | 16:9 |
| Resolution | 1366x768 |
| Color | 8Bit,16.7M |
| Brightness (nits) | 450cd/m2 |
| Contrast | 4000:1 |
| Visual angle (H/V) | 178° |
| Response time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| Input and output | |
| Composite Video Input | 3(3xBNC) |
| YUV/YPbPR | 1(3xBNC) |
| S-YC | 1(2xBNC) |
| D-15 RGB Input(VGA) | 1 |
| HDMI | 1 |
| DVI | 1 |
| Audio Input | 1 |
| Composite Video Output | 2(2xBNC) |
| Splite Screen | Support Picture in Picture(PIP/POP/PAP) |
| Power | |
| Power supply | AC100V~240V |
| Maximum power consumption | 250W |
| Standby power consumption | <=3W |
| Temperature | |
| Working temperature | 0°C~50°C |
| Working humidity | 20%-80% |
| Appearance | |
| Product dimension( W x H x D) mm | 1025.65x579.84x126.73 |
| Acessory | |
| Cable | Can supply different kinds of cable |
