WINSUN 8 Wireless Remote Control Switch Receiving Board Eight Way Controller of Each Path Can be Arbitrarily Set Point Self-lock

Eight wireless receiving plate (each path can be arbitrarily set point self-locking) remote control switch,needThe eternal 12V DC power supply to the power supply receiving board

Use:

Load control type: signal control, lighting, energy-saving lamps, fluorescent lamps, such as various types of motor load. After receiving the signal, relay and work. Used in remote control electric door, window, switch, security and other remote areas.

Characteristic of remote control switch:

The use and performance inde

1 Product Name: eight remote control switch

2 working voltage: DC12V

3 static current: 15mA

4 working frequency: 315MHz (315MHz ~ 433MHz frequency optional)

5 receiving sensitivity: -103dBm

6: the code encoding

7 state output: move / lock (each road can be arbitrarily selected)

8 dimensions (LWH): 109*76*17mm

Operation method:

1 yards: hold on learning learning key, indicator lights, press the remote control of any key, the lights flash three times, said the success of the code.

2 delete code: press the button to learn, learning the light until the lights, said clear success.

3 state output settings:

The eight remote control switch can be arbitrarily set one or several road output state (point or lock)8p pin on the motherboard respectively corresponding to each output state with a short piece of short connected with any one, corresponding to the way output state is set to: "locking" short answer otherwise the output state is: "move"
