Double socket tee with flange branch fitting for DI pipe

Specifications

Socket flange tee pipe fitting for ductile iron pipe

Double socket tee  with flange branch pipe fitting

1 Material: ductile iron GGG500-7 ,450-10

2 Specification: DN80-2000,K12,PN10/16/25

3 Standard:ISO2531,BS EN545/598 ,BS4772 ,ISO7005-2,EN1092-2, BS4504,ISO4179,ISO8179,DIN2501

4 Ceritificate:ISO9001, ISO14001,ISO18001 certificates and ISO2531,BS EN545 Certificates.

5 Characters :  high quality with  Best price,good after-sales service.

6 Protection : cement mortar lining, meatallic zinc plus black Bitumen coating/ blue/red painting ;

                        or internal and external Fusion bonded epoxy coating;

                        or internal and external Epoxy liquid painting,

                        or internal and external anti-corrosion zinc paint;

7 accesorry:  bolts&nuts , flange gasket, rubber rings are available unpon required.

1. The DI pipe fittings are ISO2531  standard,PN16.

2.  Materials : Ductile iron GGG500/7 .

3.  Coating:  DI pipe fittings inside  cement mortal lining as per ISO4179 ,
   outside with zinc primer  and bitument painting according to ISO8179  .
4- Rubber Gaskets of EPDM or SBR is in accordance with the international.
