Home > Products > Ductile Iron Tees > Ductile Iron Tee
Ductile Iron Tee
- QING DAO
- T/T
You May Like
Product Details
| Material | Iron | Technics | Casting | |
| Type | Tee | Place of Origin | Shandong, China | |
| Model Number | DN300*300 | Brand Name | TD | |
| Connection | Female | Shape | Equal | |
| Head Code | Other, Round |
Product Description
Specifications
ductile iron tee1.Standards:ISO2531 EN545/598 BS4772
2.Specfication:DN50-DN2000
3.Cement Mortar Lining ,Zinc plus Bitumen
Ductile Iron All Socket Tee
Composition of raw material:
l C: 3.4 - 3.7%
l Si: 2.0 - 2.4%
l P: ≤0.08%
l S: ≤0.015%
l Mg: 0.03 - 0.08%
l Mn: ≤0.30%
Average Density of Metal is approximate 7050kg/m
2. Mechanical Properties
Item | Tensile Strength N/mm2 | Elongation % | Proof Stress N/mm2 | Hardness HB | ||
DN80 to DN2000 | DN80 to DN1000 | DN1100 to DN2000 | DN80 to DN1000 | DN1100 to DN2000 | ||
Fittings | ≥420 | ≥5 | ≥300 | ≤230 | ||
3. Works Test Pressure
DN | Minimum hydraulic test pressure (bar) |
Fittings | |
60 to 300 | 25 |
350 to 600 | 16 |
700 to 1000 | 10 |
1100 to 2000 | 10 |
5. Internal Lining
| Fittings |
Standard Coatings | Cement mortar |
Reinforced protections | Epoxy Resin/Epoxy Powder |
Special coatings | Please consult us |
6. External Coatings
| Fittings |
Standard Coatings | Basic protection |
Zinc rich paint + Bituminous paint | |
Reinforced protections | Basic protection + |
Epoxy Resin/Epoxy Powder | |
Special coatings | Please consult us |
