Introduction of cement equipment

1.Mining system
limestone mining advanced technology, fine equipment, the equipment have the big type drilling rig, mucking equipment and transport cars, the blasting used quarry bench, middle-deep hole, non-electrical short-delay extrusion, safe blasting, big block ratio small, the blasting can reach to no waste production and make full use of the limestone resource.

2.Raw material crushing system
Single-stage hammer crusher break up the limestone, the max size 1500mm of limestone break up less than 70mm one time, technology process is simple, stable ,advanced, having the package dust collector, enviroment cleanning, meet the environmental protection requirement.
3.Raw material homogenization and storage system
A.Limestone homogenization store
Using the long or rounded pre-homogenization silo, homogenization result well , the program control automatically stacker and reclaimer operation.After homogenization limestone chemical composition is stable.
B.Clay and sand rock homogenization store
Using the long pre-homogenization silo , homogenization result well ,stacker and reclaimer according to the clay characteristic automatically control operation ,After homogenization clay and sand rock chemical composition is stable.

4. Raw material mixing system
Rely on the local raw material resouce , select limestone , sand rock , clay , iron raw material .etc , to mix and produce.Upper raw material though the homogenization to mixing system , relying on the cement special mixing formula, using the advanced electrial belt weight to accurately measurement produce
5. Raw material grinding and waster gas processing system
Using the advanced vertical roll mill technology , outfitting advanced electrial dust collector and package dust collector ,after the grinding raw material quality well , fine controllable , low energy , output friendly to enviroment.
6. Raw material homogenization and into kiln system
Adopted the continuous raw material homogenization storeage technology , take the after grinded raw materials homogenization again , used the advanced X-ray analyzer , making the raw material quality monitoring,adusting the kinds of raw material mixing on time , meet for the quality requirements.
7. Clinker calcining and waste heat power generation system
Adopted advanced pre-separate dry type rotary kiln cement production technology , equiping Yigong machinery independent research and development automatic control program ,control production stable , product quality well , low coal waste , low energy and other main economic indicators reached international advanced uced NOX ,dust , noise and inverter technology application and other sides have the Yigong special advantages.used the kiln tail and head 's waste gas waste heat resouce , taking the significant result ,under the daily output 5000t clinker production ,used vertical roll grind technology , coal power low energy , product quality meet for production need , used coal power special antistatic package dust collector , the density of coal power output less than country standard , according to the coal power flammable and explosive characteristc , designed the automatically check , alarm , fire-proof system , the whole system safe and stable.
8. Clinker input bin and bulk cement transport
according to the market difference need , can provide car , train and ship three type clinker saling , also meet for the factory self grinding cement.
9. Cement mixing and grinding system
According to the cement kind difference need , mixed adequate gypsum and mixed material , through high precision scale mixing material to input cement mill ,in order to produce high quality cement adopted the advanced quality monitor to tracking , monitoring and adjustment.The cement grinding equipment can rely on the difference need to select roll pressor system , taking the high efficiency select dust system and vertical roll mill system , cement mill used the high efficiency package type dust collecting technology .meeted for the enviromental protection high standard output requirement .
10. Cement storing and transportting system
Though grinding cement are stored round roll bin, after series of strict chemical and physical test,right cement can be as the finished product sale. Sling type according to customer need,select car bulk packing, train bulk packing, ship bulk packing and car bag packing, train bag packing.

Just contact me, we can send the engnieer to your working place and help you design the cement factory.
