RH-218 Fabric Inspection Machine with Edge Cutter
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Automatic Grade | Semi-Automatic | |
| Place of Origin | Jiangsu, China | Brand Name | REHOW | |
| Model Number | RH-218 | Voltage | 380v | |
| Power(W) | 2.2kw | Dimension(L*W*H) | 1350*2800*2000 | |
| Weight | 1200kg | Certification | ce | |
| Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
RH-218 Fabric Inspection Machine with Edge CutterGood performance with high quality
High quality, low price
RH-218 Fabric Inspection Machine with Edge Cutter
Application:
The machine is for chemical fiber fabrics, nonwoven fabrics, wire-mesh cloth, after inspection, trims directly into the tube packs. It can also be used by more knife-cut take-up, or for post-mortem volume of direct coiling.
Technical Feature:
1, Good performance with high quality
2,Use double-frequency control to adjust tension, both thick and thin fabric can adapt
3,Equipped with a photoelectronic exploration device, to which promote edge accuracy
4,Use computer counter to calculate the length and the yard of fabrics
5,Adopted the light device to enhance inspection quality
6,Clod cut, the aerodynamic configuration cold cutter, through the air pressure to control, adjust the knife pressure-thick, thin may apply
7,Hot cut, targeted vertical electric heating knife, only 180W single/double-throw power control and temperature control regulator combination, in accordance with requirements of self-regulation and control settings
Technical Parameters:
1,Effective width | 1800mm~3500mm(optional) |
2,Winding diameter | 480mm |
3,Take-up speed | 0~60 m/min |
4,Correcting category | Hydraulic type photoelectric probe |
5,Tension adjustment | 0~400n |
6,Power | 1.5~2.21kw |
7,Weight | about 1000KG |
8,Dimension | 1350(L)*2800(W)*2000(H)mm |
