RH Turntable Uniform Humidifier

Specifications

RH Turntable Uniform Humidifier

Application:

1,Suitable for textiles, non-woven fabric, wood, paper product, film and printing etc industry uniform low to liquid.

2,Entry of the shrinking machine, pre-shrinking/finishing machines, napping machine, calendaring machine, steaming machine and decatizing machine.

3,Entry or exit of the setting machine.

Technical Features:

1,Without contact, liquid feeding uniformity and without liquid droplet and water track form.

2,Without tension treatment, without change the fabric structure.

3,The liquid feeding amount with cloth speed show linear adjustment, ensure to pass direction of the front and back fluid volume is uniform.

4,According to set parameters of the fluid feeding volume, keep fluid feeding amount is not change and good reproducibility.

5,Between fabric and treating liquid is not changed, avoid possibility of the solution contamination fabric.

6,Easy to install, less ground demand, long service life, operates simply and easy to use.

Technical Parameters:

1,Size of complete machine:2810(L)*420(W)*400(H)MM

2,Pressure of water source: ≥2kg/cm2

3,Control air pressure: ≥2kg/cm2

4,Power supply: 380V

5,Effective width of humidifying:1800-2800MM

6,Total power of motor:0.75KW
