ZNEN MOTOR FOSTI- The Most Popular Cheap VESPA Scooter in EUROPE

Specification

Drive system

Belt drive

Front and rear shock

Front hydraulic rear spring shock

Electric and speedmeter

Eight level direct current , 12V7A battery,speedmeter(speed,mileage,fuel tank capacity)

Lighting system

Front headlamp,front winker,rear tail light

Exhaust system

Mute exhaust

Switch control system

Function left and right swtich

Cylinder diameter

39 mm

Piston stroke

41.5

Battery type

12V7A

Max power and rotate speed

2.0KW(2.72HP)/7000rpm

Max torque and rotate speed

3.01/5000(N.m/rpm)

Minimum ground clearance(mm)

125

Compression ratio

10.2:1

Unladen mass(kg)

91

Load capacity(kg)

150

Economic oil consumption

≤2.0

Climbing capacity

Angle: 30 degrees

Minimum turning radius

1750MM

Speed change

V type belt stepless speed change

Package information

Gross weight(KG)

114KG(CBU iron package disassemble the front wheel)

109KG(SKD iron package)

Net weight(KG)

91

Packing mode/quantity

CBU iron package disassemble the front wheel 50pcs (40*GP)

CBU full carton package disassemble the front wheel 50pcs (40*HQ)

SKD iron package 75pcs (40*HQ)

SKD full carton package 75pcs (40*HQ)

Package size(mm)

CBU iron package disassemble the front wheel 1900*580*1120

CBU full carton package disassemble the front wheel 1900*580*1120

SKD iron package 1900*580*860

SKD full carton package 1900*580*860
