HUAQIU BJ-9A fire fighting pump

1. HUAQIU BJ-9A fire fighting pump is powered by GX270 high efficient gasoline engine and the single-level centrifugal pumps of Zhejiang WOQ Machinery Manufacturing Co., Ltd. It has features of compact structure, start convenient, fast water, low fuel consumption, light weight and reliable, so that is more suitable for using in the narrow roads. It is the ideal equipment for fire extinguishing used in fire brigade, professional fire brigade, forest fire brigade, towns, rural areas, the mining industry and obligation fire brigade.


Engine and pump castings are made of anti-corrosive aluminum-alloy to reduce weight and prolong working life. Compact unit in its class fits existing locker space, also can be carried by 2 firemen.

2. HUAQIU BJ-9A fire fighting pump technical parameters:
Appearance dimension L×W×H: 650×565×510mm;
Pump Intake Sop Caliber: Φ65mm;
Pump outlet Water Exceeding Caliger: Φ65mm;
Device weigh Dry Weight: ≤56kg;
Maximum output power Maxinmum Torque: 11Hp/3600r/min;
Starting way Way Of Starting : Hand starter / electric starter;
Rated flow pump At Rated Pressure: 540L/min/0.5Mpa;
Pump priming time Priming Time : ≤20s;
Maximum suction depth

Sucation Head Max: 7m
Pump lift: 55m

3. HUAQIU BJ-9A fire fighting pump Picture

4. HUAQIU BJ-9A fire fighting pump workshop Pictures

5. HUAQIU BJ-9A fire fighting pump Certificates
