6TG-E120X1235QZ Front End Telescopic Hydraulic Cylinder for Dumping Carts

Specifications:

1. All Seals: Manufactured to US specification;

2.Ports: NPTF(SAE port or other can be available);

3.Piston: Ductile iron ASTM A536 65-45-12 for excellent life

4.100% hydro-pressure test;

5.Rod surface treatment: Superior quality chrome plated;

6.Apply LOCTITE to rod end thread;

7.Ductile iron gland, drilled oil passages.
8.Honed steel tube, precision finished for extended seal life.

Custom Hydraulic Cylinder

We can supply customized hydraulic cylinders with drawings or samples, or if you could provide following specification:

•diameter of bore & rod
•stroke
•mounting style
•mounting distance
•working pressure
•ports
•seals
•special modifications

Widespread Application

We specialize in design and manufacture hydraulic cylinders that are used in a variety of fields including:

•Construction Machinery cylinders for: loaders, excavator, forklift, bulldozer, dumper, roller, crane etc.
•Metallurgical Machinery cylinders for: decelerator, tile press etc.
•Mining Machinery cylinders for: crasher, coal cutter etc.
•Agricultural & forestry machinery cylinders for: soil preparation machine, harvester, weeder etc.
