Approval Sales Segway Self Balancing Scooter Flexible Fpc Board

Approval Sales segway self balancing scooter flexible fpc board

Feature of touch panel FPC :

1. Flat Flex pcb with different pitch
2. Customize Length
3. Customize Contact: 0.2mm,0.3mm,0.4mm,0.5mm,1.0mm,1.25mm
4. UL Cable & ROHS compliant

Discription of touch panel FPC :

1. Wide Pitch Range: 0.2mm,0.3mm,0.4mm,0.5mm,0.8mm ,1.0mm ,1.25mm,1.27mm, 2.0mm,2.5mm
2. FPC Custom Length: 15mm ~ Longer available
3. FPC Pin Number: 3-100 (custom cable service is provided)
4. FPC Wire Material : UL Style:2896 80C,30V,UL STYLE: 20624 80C,60V
5. All products compliant with ROHS
6. Simplify layout procedure and simplify wiring.

FPC Application:

1.Notebook computers, LCD Display, Optical drive, Hard disk;

2.Printers, Fax machines, Scanners and Sensors;

3.Mobile phone, cell phone batteries, walkie-talkie, mobile phone antenna, mobile phones dual SIM Card, phone cable;

4.All kinds of high-end camera, digital camera, digital camera, DV,

5.VCR magnetic head, laser sensor,CD-ROM,VCD,CD,DVD;

6.Aerospace, satellite/medical equipment, instrumentation, automotive instrumentation;

7.Light bar, LED FPC flashing lights, toys, collar, lamp decoration.

Testing Procedures For FPC Board
---We perform multiple quality assuring procedures before shipping out any PCB board. These include:
Visual Inspection;
Flying probe;
Bed of nails;
Impedance control;
Solder-ability detection;
Digital metallograghic microscope;
AOI (Automated Optical Inspection).

1. Company History: Zhengte is a electronic manufacturer specialising in PCB production,PCB assembly ,as well as PCB design .
2. Product Series: Double-side PCB,multilayer PCB,HSAL PCB,ENIG PCB,Aluminum PCB,HDI PCB,Felxible PCB,Rigid PCB,PCBA,Electronics Assembly ,etc.

3. Enterprise Scale: more than 3000 square meters, more than 200 staffs

4. Certificates: RoHS, ISO9001: 2008 , ISO14001:2004,TS16949,UL etc.

Production line

Certifications

What is your minimum order quantity?

We have no limitation on MOQ, prototype, medium volume and large volume are all acceptable.

How to Place order with Zhengte Electronics?

Step1: Send us the PO with request (Final project files confirmed) and we will confirm with PI.

Step2: The order will be entered into our order system in same day.

Step3: Deposit or full payment complete,then order confirmed by our financial department.

Step4: The order will be proceed accordingly by our purchasing system.

Step5: Sample or photos offered for approval.

Step6: Balance payment complete,shippment arranged and tracking will be offered via email.

What is your testing policy and how did you control the quality normally?

Usually , sample was tested by flying probe and PCB Volume over 3 square meters, will be tested by fixture .

Are my design files safe when I submit them to you for manufacturing?

Any customer’s file will be protected very well here in our factory and we will not let any third party know. We can sign NDA with you.

How can make sure no mistake for mass production?
The production files will be checked by our engineering teams.Samples will be
offered for approval before mass production.

What files in need for the PCB/FPC Assembly services?
Besides the PCB files and Components list,we also need PNP(Pick and Place)
and Components Position files for production.

How can I track the shipment?

When order complete,an email will be sent out to confirm the value and shipment methods.

Then the shipment tracking number will be shared with email as always.

For more question, please contact us anytime .
