The lowest price double-sided pcb sample and pcb prototype
- 5000 Square Foot / Square Feet per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
Good quality led electronic PCB Manufacturer for customized electronic led PCBA
-
printed circuit board and led pcb design
-
FR-4 Electronic PCB supplier in China
-
Aluminum led round shape single sided PCB
-
Electronics manufacturing aluminum pcb
-
hot selling 2015 custom design home theater fr4 circuit board pcb
Product Details
| Place of Origin | Guangdong, China | Brand Name | OEM ODM | |
| Model Number | ZT-B106-4L0008 | Number of Layers | 4-Layer | |
| Base Material | CEM-1 CEM-3 | Copper Thickness | 35um | |
| Board Thickness | 1.6mm-3.2mm | Min. Hole Size | 0.2mm-6.3mm | |
| Min. Line Width | Min. Line Width: 3mil (0.075mm) | Min. Line Spacing | 0.1um(3mil) | |
| Surface Finishing | HASL,Immersion Gold,Immersion Silver,Immersion Tin,OSP... |
Product Description
The lowest price double-sided pcb sample and pcb prototype
Item | Capability | |
1.Base Material | FR-4 / High TG FR-4 / Lead free Materials (ROHS Compliant) / Halogen Free material /CEM-3/CEM-1/ /PTFE/ROGERS/ARLON/TACONIC | |
2.Layer No. | 1-18 layers | |
3.Finised inner/outer copper thickness | 1-6 OZ | |
4.Finished board thickness | 0.2-7.0 mm | |
Tolerance | Board thickness≤1.0mm: +/-0.1mm 1<Board thickness≤2.0mm: +/-10% Board thickness>2.0mm: +/-8% | |
5.Max panel size | ≤2sidesPCB: 600*1500mm Multilayer PCB: 500*1200mm | |
6.Min conductor line width/spacing | Inner layers: ≥3/3mil Outer layers: ≥3.5/3.5mil | |
7.Min hole size | Mechanical hole: 0.15mm Laser hole: 0.1mm | |
Drilling precision: first drilling | First drilling: 1mil Second drilling: 4mil | |
8.Warpage | Board thickness≤0.79mm: β≤1.0% 0.80≤Board thickness≤2.4mm: β≤0.7% Board thickness≥2.5mm: β≤0.5% | |
9.Controlled Impedance | +/-5% | |
10.Aspect Ratio | 15:1 | |
11.Min welding ring | 4 mil | |
12.Min solder mask bridge | ≥0.08mm | |
13.Plugging vias capability | 0.2-0.8mm | |
14.Hole tolerance | PTH: +/-3mil NPTH: +/-2mil | |
15.Outline profile | Rout/ V-cut/ Bridge/ Stamp hole | |
16.Surface finished | OSP: 0.5-0.5um HASL: 2-40um Lead free HASL: 2-40um ENIG: Au 1-10U’’ ENEPIG: PB 2-5U’’/ Au 1-8U’’ Immersion Tin:0.8-1.2um Immersion silver: 0.1-1.2um Peelable blue mask Carbon ink Gold plating: Au 1-150U’’ | |
17.E-testing pass percent | 97% pass for the first time,+/-2%(tolerance) | |
FQC-Physical Lab: Reliability tests | ||
18.Certificate | ROHS UL:E327776 ISO9001:2008 IPC SGS | |
Application
Widely used in consumer electronic products, electrical appliances, small household electrical appliances, communication products, automotive, medical equipment and other fields (such as mobile phone, telephone, LED lighting equipment, TV, DVD, computer products and peripherals, game consoles, charger, power adapter, remote control and home appliances).
Details
1. Related Certificate --- UL ,ISO9001:2000 , TS16949, RoHS.
2. 100% electrical test, AOI testing, four times 100% QC inspection beofre shipping.
3. High reliable, Germany equipment ,competitive price andSpeedy delivery.
4. Fast Prototype Service.
5. One stop electronic assembly service(provide prototype, plastic injection molding, part painting,
components purchasing, SMT COB,DIP,PCBA service as one unit).
PCB package way : Vacuum package + desiccant bag
Delivery
Advantage
1.Fast PCB Fabrication for Samples and Mass Production
2.Electronic Components Sourcing Services
3.PCBA Assembly Services:SMT,DIP,BGA...
4.Function Test
5.Stencil and Enclosure Assembly
6.Standard Packing and On time Delivery
1. Company History: Zhengte is a electronic manufacturer specialising in PCB production,PCB assembly ,as well as PCB design .
2. Product Series: Double-side PCB,multilayer PCB,HSAL PCB,ENIG PCB,Aluminum PCB,HDI PCB,Felxible PCB,Rigid PCB,PCBA,Electronics Assembly ,etc.
3. Enterprise Scale: more than 3000 square meters, more than 200 staffs
4. Certificates: RoHS, ISO9001: 2008 , ISO14001:2004,TS16949,UL etc.
Production line
Equipments
Certifications
Q: How can I get quotation in time?
A: Please send us the PCB File and Components list via mail or Online tool(Aliwangwang or Skype,WhatsApp)The file will be checked and the initial quotation will be offered withing 2 working days as usual(Gerber,Eagle,PCB,CAD file are acceptable).
Q: How to Place order with Zhengte Electronics?
A:
Step1: Send us the PO with request (Final project files confirmed) and we will confirm with PI.
Step2: The order will be entered into our order system in same day.
Step3: Deposit or full payment complete,then order confirmed by our financial department.
Step4: The order will be proceed accordingly by our purchasing system.
Step5: Sample or photos offered for approval.
Step6: Balance payment complete,shippment arranged and tracking will be offered via email.
Q: What's the normal sequency of order?
A:
Step1: * PCB board file with parts list details provided by customers.
Step2: * PCB board file checked by PCB engineer.
Step3: * PCB board components sourced by Zhengte Electronics.
Step4: * Components checked by Zhengte Electronics warehouse stuffs.
Step4: * PCB board with components assembled.
Step5: * Electronic testing circuit board or PCBA.
Step6: * Anti-static package,Fast delivery.
Q: How can make sure no mistake for mass production?
A: The production files will be checked by our engineering teams.Samples will be
offered for approval before mass production.
Q: What files in need for the PCB Assembly services?
A:Besides the PCB files and Components list,we also need PNP(Pick and Place)
and Components Position files for production.
Q: How can I track the shipment?
A:When order complete,an email will be sent out to confirm the value and shipment methods.
Then the shipment tracking number will be shared with email as always.
Q: How can I share the feedback?
A: Please send the comments with the order number within 30days to our feedback service department.Our service department will proceed in working days as usual.
Q: What service Zhengte Electronics can offer?
A: One stop service for PCB design,PCB layout,PCB manufacture,Components purchasing,PCB assembly,Testing,Packing and PCB delivery.
