front end loader 3 point hitch

FOB Price

USD $4,000 - $7,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Brand Name	kanghong
Model Number	ZL10F	Place of Origin	Shandong, China
Type	Front Loader	Moving Type	Wheel Loader
Dimension(Long * Breadth * High)	4800x1600x2470	Rated Load	800kg
Certification	CE/ISO	Warranty	12 months quality assured
After-sales Service Provided	Overseas third-party support available

Performance	Rated Load	1000 kg
	Total weight	2700 kg
	Rated Bucket Capacity	0.4 m3
	Max.Gradeability	30°
	Dumping Height	2700mm
	Overall Dimemsions(LxWxH)	4800x1600x2470
	Min.Turning Radius	3900mm
Engine	Model	changchai L28 diesel engine
	Type	In-line,Water-cooled,Four-stroke,Direct injection, single- cylinder
	Rated Power	20 kw
	Rated Speed	2200 rpm
Transmission	Gear box	countershaft powershift gearbox
	Torque converter	Stick Shift,without TC
	Gear Shift	2 forward,1 reverse
	Max.Speed	25 km/h
Drive Axle	Model of Axle	Isuzu Axle
Drive Axle	Wheel Base	1950 mm
Hydraulic System	System Working Pressure	16 Mpa
	Raising Time	≤ 4.5 s
	Total Cycle Time	≤ 9.0 s
	function of leveling automatically	Yes
Brake system	Service Brake	Hydraulic,Expansion-shoe Brake on 4 wheels
Brake system	Parking Brake	No parking brake
Tyre	Type Specification	825-16
	Front Tyre Pressure	0.3 Mpa
	Rear Tyre Pressure	0.28 Mpa

2014 New zl10f mini loader shovel agricultural equipment for sale with CE low prices alibba China

1.well-known engine brand, low noise, low fuel consumption, reliable operation and long service life.

2.Countershaft design, power-shift gearbox,Three elements single stage torque converter easy to operate

3.Split flow of single pump for working hydraulic system, significant effect of energy conservation;

4.Double sealed hydraulic pipeline joints with 24° awl and O ring of international standard, avoids oil leakage obviously;

Safe and reliable disk brake system

5.Working device with automatically leveling ability at high position;

6.Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability;

Integral, luxury instrument board;New, luxury cabin.

7.Optimized electric system .key electric elements are imported from EU and US,and the system reliability and stability.had been improved

8.New cooling system improves performance, -20~+40 ambient temperature capability
