High Screening Efficiency sand washing machine for Mining, spiral classifier sand washing machine
USD $1,000 - $10,000
/ Set
1 Set(Min.Order)
- SHANGHAI
- T/T
You May Like
-
High Precision Sand Washing Machine With Large Productivity , spiral classifier sand washing machine
-
High efficency good quality long distance belt conveyor in mining made in China
-
High Screening Efficiency sand washer XL-915, spiral classifier sand washing machine
-
High Screening Efficiency sand washing machine 2XL-915, spiral classifier sand washing machine
-
High Screening Efficiency sand washing machine XL-1115, spiral classifier sand washing machine
-
Hot Selling small sand washer/sand washer/sand crushing line
Product Details
| Condition | New | Motor Type | AC Motor | |
| Power(W) | 20-40(KW) | Capacity(t/h) | 50-500 | |
| Place of Origin | Shanghai, China | Brand Name | TRUSTON | |
| Model Number | spiral classifier sand washing machine | Dimension(L*W*H) | see the specifications | |
| Weight | see the specifications | Certification | ISO. CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
spiral classifier1.single spiral classifier
2.double helixes spiral classifier
3.high weir type
4.immersed weir type
High Screening Efficiency sand washing machine for Mining, spiral classifier sand washing
1. Spiral Classifier Sand WasherSpecifications
| Model | Screw Diameter(mm) | Selected Size(mm) | Capacity(t/h) | Power(kw) | Weight(kg) |
| XL-915 | 915 | <10 | 100 | 11 | 6585 |
| 2XL-915 | 915 | <10 | 200 | 11×2 | 11555 |
| XL-1115 | 1115 | <10 | 175 | 18.5 | 10710 |
| 2XL-1115 | 1115 | <10 | 350 | 18.5×2 | 16700 |
| XL-1370 | 1370 | <10 | 250 | 30 | 14530 |
| 2XL-1370 | 1370 | <10 | 490 | 30×2 | 25610 |
| XL-1676 | 1676 | <10 | 360 | 45 | 18570 |
| 2XL-1676 | 1676 | <10 | 725 | 45×2 | 41930 |
| 2XL-1830 | 1830 | <10 | 860 | 55×2 | 18570 |
| XL-928 | 928 | <65 | 155 | 22 | 6200 |
| 2XL-928 | 928 | <65 | 315 | 22×2 | 10990 |
| XL-1118 | 1118 | <75 | 225 | 30 | 9300 |
| 2XL-1118 | 1118 | <75 | 450 | 30×2 | 16350 |
| XL-905 | 905 | <75 | 125 | 110 | 22800 |
| XL-1120 | 1118 | <100 | 175 | 160 | 31950 |
2. Sand Washer Introduction
Sand washer is suitable for washing, classifying and dewatering of sand used in construction, quarry, hydropower station, concrete dam project, pole factory, as well as "soul-rending nature sand" for casting use,quartz sand for glassworks, and pressure sand for oil well backfill. With inclination angle of 180 , a setting pond is formed and surrounede by three-side plates at the bottom of water channel.The spiral head submerges into the setting pond,the spiral rotates continuously driven by motor and reducer, and clean water is fed into setting pond through the bottom perforated plate.
| |
| |
| |
