Compatible with SMP650V thermal printer mechanism JX-2R-02
Negotiable
/ Piece
100 Pieces(Min. Order)
- Xiamen China
- T/T Credit Card PayPal
You May Like
-
For Samsung SMP650V thermal printer mechanism JX-2R-02
-
Compatible with SMP640 thermal printer mechanism JX-2R-04
-
For Samsung SMP640 thermal printer mechanism JX-2R-04
-
Compatible with SMP640V thermal printer mechanism JX-2R-04A
-
For Samsung SMP640V thermal printer mechanism JX-2R-04A
-
Compatible with FM205HS thermal printer mechanism JX-2R-01
Product Details
| Place of Origin | Gansu, China | Brand Name | Jingxin | |
| Model Number | JX-2R-02 |
Product Description
Specifications
1.ROHM thermal head2.Wide voltage range
3.Light weight
4.For SMP650V
5.Cost-effective thermal printer mechanism
1. Why choose us?
1) ROHM's thermal printer head.
2) Over 20 years' experience of engineers team.
3) Unique product design & obtained Chinese patents certificates.
4) Advanced Japan equipments.
2. Product basic information
Brand: Xiamen Jingxin
Name: Compatible with SMP650V thermal printer mechanism
Model: JX-2R-02
Material: ROHM TPH, FPC, rack, drive, screw, platen, gear, spring and lead paper holder etc.
| Printing method: | Thermal dot line printing |
| Printing width: | 48mm |
| Printing speed: | 80mm/s |
| Printing life: | ≥50km |
| Motor voltage: | 4.2-8.5VDC |
| Paper cutting: | Manual |
| Path of paper traveling: | Perpendicular bend |
| Operating machine noise: | 60db (max) |
| Mass: | 34.7g |
| Size: | L=71.3mm,W=32.7mm,H=15.6mm,L(FPC)=71mm |
| Use of: | Portable printer/ POS payment terminals |
3. Products pictures
4. Certificates
1)
Certificate Standard: ISO 9001:2008
Number: CN-0212Q1127OROS
Issue Date: 13-Mar-2012
Expiry Date: 12-Mar-2015
2 )
Certificate Standard: ROHS
Number: SH9033426/CHEM
Issue Date: 18-Mar-2009
3 ) Patents of our company
5. Factory Views
