Home > Products > 3 inches thermal printer mechanism > 83mm auto cutter thermal printer head JX-3R-022AP/AF
83mm auto cutter thermal printer head JX-3R-022AP/AF
- Xiamen China
- T/T Credit Card PayPal
You May Like
-
3 inches epson printer spare parts thermal head JX-3R-022B
-
83mm high speed epson thermal printer head JX-3R-022AP/AF
-
3 inches thermal printer usb print head JX-3R-07
-
For Fujitsu FTP628MCL101 3d printing head JX-2R-01B
-
high speed 58mm thermal barcode printer head JX-2R-17
-
Adjustable thermal printer mechanism JX-2R-01B
Product Details
| Place of Origin | China | Brand Name | Jingxin | |
| Model Number | JX-3R-022AP/AF |
Product Description
Specifications
1.ROHM TPH2.Low noise,Cost-effective
3.High printing speed
4.Compatible with Epson M-T542AF/AP
1. Why choose us?
1) ROHM's thermal printer head.
2) Over 20 years' experience of engineers team.
3) Unique product design & obtained Chinese patents certificates.
4) Advanced Japan equipments.
2. Product basic information
Brand: Xiamen Jingxin
Name: 83mm auto cutter thermal printer head
Model: JX-3R-022AP/AF
Material: ROHM TPH, FPC, rack, drive, screw, platen, gear, spring and lead paper holder etc.
| Printing method: | Thermal dot line printing |
| Printing width: | 80mm |
| Printing speed: | 150mm/s |
| Printing life: | ≥100km |
| Motor voltage: | 24 VDC |
| Paper cutting: | Auto-cutter |
| Path of paper feeding: | straight |
| Operating machine noise: | 60db (max) |
| Mass: | 535g |
| Size: | L=128mm,W=93mm,H=58mm,L(FPC)=330mm |
| Use of: | Portable printer/ POS payment terminals |
3. Products pictures
4. Certificates
1)
Certificate Standard: ISO 9001:2008
Number: CN-0212Q1127OROS
Issue Date: 13-Mar-2012
Expiry Date: 12-Mar-2015
2 )
Certificate Standard: ROHS
Number: SH9033426/CHEM
Issue Date: 18-Mar-2009
3 ) Patents of our company
5. Factory Views
