School Drawing Paper Making Machine
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Recycle Paper Scrap Toilet Tissue Paper Making Machine
-
Hot Sale! Rotary Spherical Digester Pulp Making Equipment Paper Machine Part
-
2014 Hot Sale! Band-saw Paper Cutting Machine Paper Cutter for Paper Roll
-
Napkin Facial Tissue Folding and Embossing Machine Paper Embosser and Folder
-
Set Asides Recycle Machine
-
2014 Hot Sell Crepe Paper Making Machine
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | Dingchen | Model Number | series type | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
wood plates packing
Product Description
high quality a4 paper making machine with reasonable price
1.Technical datas of a4 paper making machine:
1.Raw material: waste paper, cotton straw, wheat straw, sugar cane bagasse
2.Output paper: writing paper, culture paper, newspaper, printing paper,a4 paper
3.Weight: 60-120g/m2
4.Net paper width: 2100mm
5.Rail gauge: 3000mm
6.Capacity: 20T/D
7.Drive way: Motors with AC converter frequency & adjustable speed .Processing transmission
2.Main frame of a4 paper making machine:
Part name | Equipment | Specification | Qty(set) |
Mesh cylinder part | Cylinder mould | Φ1500mm×2400mm | 3 |
Net slot | 12 thick polyethylene plastic sheet welding | 3 | |
Couch roll | Φ450mm×2400mm | 1 | |
Reverse roll | Φ450mm×2400mm | 1 | |
Press part | Stone roll | Φ650mm×2400mm | 1 |
rubber roll | 600mm×2400mm | 1 | |
Pneumatic loaded device | |||
Dryer part | Dry can | Φ2500mm×2400mm | 2 |
Dry can | Φ1500mm×2400mm | 3 | |
Touch roll | Φ650mm×2400mm | 1 | |
Pneumatic loaded device, shore hardness is 90o±2, second and third cylinder part are equipped with dry wire. & anti-pressure device | |||
Designed type | Rack is square box, cast iron, All-pneumatic pressure | ||
Drive | Reduction box, coupling, adjustable speed | ||
Company Profile
Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines. Our company has over 420 employees. We have passed ISO14001 International Authentication. Our products include paper making machines, parts and paper processing machines such as kraft paper machines, tissue paper machines, cultural paper machines, fiber separators, hydrapulpers, rewinders, napkin folders, tissue slitters and so on. They have been exported to more than 8 countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying on advanced technologies, sincere services and inexpensive products of high quality, we have won the recognition of international markets and clients.
