7 inch 800x480 resistive touch screen which operating Temp -10-60

Specifications

Specification Circuit Grade: 5V DC,35mA Hardness: 3H Transparency Film to film>77% Touch life: >35,000,000 times Film to glass>83% Stroke life: >5,000,000 time Response time: Operating temperature: -10 oC ~+60 oC Resolution : 4096*4096 Storage temperature: -20 oC ~+70 oC Linearity : Glass Thickness: 0.7mm,1.1mm,2.0mm,3.0mm Operating force: 10g~100g Glass: general glass, Chemical Tempered Glass Specification Reliable and stable,practical and the Touch life is as many as 35,000,000times Can recognize allmedium such as finger (with the glove or not), pen, credit card and etc. The outgoing wires areFPC which is good at flexility and less in resistance than PET other manufacturers use. The insulated nod issmall (Φ 0.035mm) and thevisual effect is good. The screen has multiple choices such as polished, foggy, anti-dizzy,extinction, Anti- Newton ring and etc. Standard Dimension: Model Spec. Dimension (mm) Dimension of the screen (mm) Dimension of the driver (mm) EE-1044-IN-W5R 10.4"built-in 249.00*186.60 219.90*167.80 215.90*163.80 EE-1215-IN-W5R-B 12.1"built-in 276.00*213.00 253.00*191.00 247.00*185.00 EE-1215-IN-W5R-C 12.1"built-in 271.27*205.74 250.87*189.40 246.37*184.90 EE-1215-IN-W5R-D 12.1"built-in 265.00*209.00 247.97*186.48 245.97*184.48 EE-1413-IN-W5R 14.1"built-in 321.06*249.94 289.68*218.31 287.68*216.31 EE-1503-IN-W5R-D 15"built-in 337.00*257.00 310.00*235.00 305.00*228.00 EE-1701-IN-W5R-D 17"built-in 366.00*294.50 342.00*274.50 334.00*266.50 EE-1701-IN-W5R-E 17"built-in 362.00*278.00 340.00*260.00 320.00*238.00 EE-1908-IN-W5R 19"built-in 395.00*300.00 370.00*276.00 358.00*267.00 EE-2106-IN-W5R 21"built-in 438.00*331.00 416.60*315.00 402.60*301.60 EE-2106-IN-W5R-B 21"built-in 445.64*366.90 413.20*334.47 411.68*332.94
