high effiective fouridrinier multi-dryer corrugated paper plate making machine in china
- qingdao port
- T/T D/P D/A Credit Card PayPal
You May Like
-
low cost fouridrinier multi-dryer corrugated paper plates recycling making machine from supplier
-
low cost fouridrinier multi-dryer corrugated paper recycling making machine for wholesale
-
low cost fouridrinier multi-dryer corrugated paper making machine in china
-
low cost fouridrinier multi-dryer corrugated paper printing making machine price
-
fouridrinier multi-dryer corrugated paper machine/ kraft recycled paper paper plate making machine price
-
new fouridrinier multi-dryer corrugated paper making machine/ waste paper recycling machine to make pulp for sale
Product Details
| Condition | New | Product Type | Other, kraft/corrugated paper making | |
| Processing Type | Other, kraft/corrugated paper making machine | Place of Origin | Henan, China | |
| Brand Name | Dingchen | Model Number | corrugated paper machine | |
| Voltage | 380V 50HZ | Power(W) | 15KW | |
| Dimension(L*W*H) | 2950*1320*1500mm | Weight | 2500kg~3000kg | |
| Certification | Other, ISO9001 | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Wooden box, wooden support, oilpaper and others
Containers: 40' high cubic, 40' flat rack
Product Description
high effiective fouridrinier multi-dryer
corrugated paper plate making machine in china
I. Technical parameter:
1. Raw materials: recycled paper
2. Output paper: liner paper, kraft paper, corrugated paper
3. Output paper weight: 120-200g/m2
4. Capacity: 60 T/D
5. Net paper width: 2600mm
6. Cylinder mold width: 3000mm
7. Working speed: 90-130m/min
8. Designing speed: 150m/min
9. Rail gauge: 3500mm
10. Drive way: A/C converter speed controlling, sectional drive.
II.Paper machine equipment
No. | Item & Description |
1 | 2600mm multi-cylinder mold multi-dryer can liner paper making machine |
3 | Semi-closed dryer hood |
4 | Axial-flow ventilator |
5 | 16 type Roots vacuum pump |
6 | Suction box |
7 | Air compressor |
8 | 2 rolls Calender |
9 | Frequency conversion controlling cabinet |
10 | 2600mm Horizontal pneumatic winding machine |
11 | 2600mm High-duty frame type rewinding machine |
12 | Sizing machine |
13 | 6T boiler (burning gas) |
14 | Slat conveyor |
15 | hydra-pulper |
16 | Medium consistency sand remover |
17 | High density sand cleaner |
18 | Pressure screen |
19 | 35 m3 bleacher |
20 | Vibrating screen |
21 | φ380 double-disc pulp refiner |
22 | φ700 impeller |
23 | 606 sand remover |
24 | Electric operation cabinet |
Flow chart
Raw material
Paper
Technical Advantage
1Experienced producing team
2.Advanced technological strength
Product advantage
1.Through the international authentication
2.The same material the most preferential price
3.A lot of varieties for the customer to choose
Service Advantage
1. technical consultation;
2. project evaluation;
3. detailed design of factory;
4. installing and testing the whole production line;
5. training engineers and workers;
6. supplying spare parts for long time
If you have any questions, pls free feel contact us immediatedly, and we are waitting for your inquiry information
Company Profile
Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines. Our company has over 420 employees. We have passed ISO14001 International Authentication. Our products include paper making machines, parts and paper processing machines such as kraft paper machines, tissue paper machines, cultural paper machines, fiber separators, hydrapulpers, rewinders, napkin folders, tissue slitters and so on. They have been exported to more than 8 countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying on advanced technologies, sincere services and inexpensive products of high quality, we have won the recognition of international markets and clients.
