Warehouse racking

FOB Price

USD $80 - $120 / Set

50 Sets(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Xianfu
Use	Warehouse Rack

Feature: 1.Loading capacity: 500kgs -3500kgs;2.Material:steel; 3. Powder coating & spray painting;4. All size available

Features:	Beam levers are adjustable in 75mm pitch interval. Different sizes, various specifications and colors are available according to customers’ different needs. Maximizes space use ratio in any warehouse configuration while retaining optimum product accessibility. Strength and rigidity prevents compression damage to goods. Bottom level of pallets can be stored on the floor, lowering structure costs.
Load Capacity & Dimension:	Loading capacity: 500-2500 kgs UDL/beam level. Height: 1000-10000mm Depth: 400-1500mm Length: 1500-3600mm Specail sizes also avaiable to specific storage needs.
Main Parts Specs:	Uprights:80x60x2.0, 90x70x2.0, 100x70*2.0, 120x95x2.0, 120x95x2.5 Box beams: 80x50x1.5, 100x50x1.5, 120x50x1.5, 140x50x1.5, 160x50x1.5 Horizontal & diagonal braces, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components.
Material:	High grade Q235B Steel
Finish:	High quality Powder Coating Finishing.

Ningbo Xianfu Metal Products Co., Ltd.: Contact nameZoe Woo
Chat Now; Phone86-574-88335650; AddressWuxiang, Ningbo, Zhejiang
