Eraser Shaped Like Game Controller Electric Current Controller Solar Charge Controller

This series is a new series of intelligent multi-purpose solar charge controllers. Its innovative design makes it easy to install and quite user-friendly. Optimized charging and discharging management extends the service life of batteries considerably. Meanwhile, parameters are explicitly displayed. Most parameter values can be set to meet various applications.

Product size:220mm*153mm*77mm
Each carton sets:12
Carton size:525mm*490mm*190mm
Single tank volume:0.052m3
Gross weight:19.5kg

Ⅰ Features

1.Intelligent, high-efficient PWM charging mode in series connection.

2.Multi-stage charging mode

3.System voltage identification: automatic identification, fixed 12V, fixed 24V, or fixed 48V.

4.The charging parameters for Gel, Sealed and Flooded batteries are preset plus adjustable “User” battery type for customization.
5.Charging and discharging parameters are adjustable.
6.Temperature compensation is applied.
7.Various controlling mode for load, regular control mode, light control mode, light control with switch-off point at night& switch-on point before dawn mode, self-timing control mode.
8.LCD presents real-time controller working status and related parameters explicitly.
9.Smart backlit function (optional).
10.Recording for Ah of charging and discharging.
11.Alternative communication, RJ45 connection port, RS232, RS485 and standard Modbus communication protocol (optional).
12.Temperature compensation is applied.
13.Protection against reverse connected solar panel or batteries.
14.Protection against reverse discharge of battery
15.Protection against input over-current from solar panel, over-current of load, overheats.

Ⅱ Technical data
