In situ sterilization glass fermenter(Magnetic drive)

Specifications

In situ sterilization glass fermenter(Magnetic Drivedrive) BLBIO-10GCAV

Models:BLBIO                  5GGCAV              7GCAV        10GCAV     15GCAV

working Volume                   2-4 Liter        3-5 Liter        5-8 Liter     7-10 Liter

Load Proportion 65-80% of total volume, 70% optimum
Vessel Material glass body and stainless steel lid and bottom

The high ratio: 2:1

Mixing method:  Magnetic  drive

Sterilization method: In situ sterilization

Control system: Siemens PLC, industrial LCD touch computer control, parameters can be set to store, can be remotely connected to the computer through the USB interface, the data

Stirring system
high-powered stirring oar, antifoam oar; AC electrical machine: infinite speed variation; rpm in the fermenter: 70~1200rpm±1%,The height of the stirring oar can be adjusted, too.

Temperature detection and control
Heat by thermostatic water tank and circulate by circulating pump(Grundfos, Denmark), autocontrol (cooling water+5°C)~65°C±0.1°C,temperature probe(US)

pH detection and control
2.00-12.00±0.05pH, autocontrol by adding acid and base, pH sensor (Mettler, Switzerland) and shielding lead (Mettler, Switzerland). fermenter is autocontrolled with peristaltic pump

DO detection and control
0-150±3% displaying precision 0.1%, sensor (Mettler, Switzerland) and shielding lead(Mettler, Switzerland)

Feed control
fermenter uses peristaltic pump (Longer) to add meterials

Antifoam control
Tested by sencor and added antifoamer by peristaltic pump

Intake control (air) :manual control rotameter
