Home > Products > Variable Frequency Power Suppy CFP > 3 Phase 380V to 440V ac Frequency Inverter 50hz/60hz//400hz
3 Phase 380V to 440V ac Frequency Inverter 50hz/60hz//400hz
US$ 4,690 - 5,210
/ Set
1 Set(Min. Order)
- Shanghai
- T/T Credit Card PayPal
You May Like
-
3 Phase 380V to 440V ac Frequency Converter 50hz/60hz//400hz
-
3 Phase 380VAC to 220VAC Frequency Converter 50hz/60hz//400hz
-
50KVA 3 Phase to Single Phase Ac-ac Frequency Converter 50hz 60hz 400hz
-
50KVA 2 Phase to 3phase Ac-ac Frequency Converter 50hz 60hz 400hz
-
45KVA Single Phase ac to ac Frequency Converter 50hz 60hz 400hz
-
45KVA Three Phase to Single Phase Ac-dc-ac Frequency Converter 50hz 60hz 400hz
Product Details
| Place of Origin | Shanghai, China | Brand Name | Nooyi | |
| Model Number | CFP33045 | Output Power | 1 - 200KW | |
| Output Type | Triple | Size | 780x650x1350mm | |
| Weight | 280kg | Input Voltage | AC380V,AC220V,AC480V | |
| Output Voltage | 0~520V adjustable | Type | Other, AC/AC | |
| Output Frequency | 50/60HZ | Output Current | 68A |
Product Description
1)Features:
| • Perfect impact resistance. (3 times pulse current) |
| • High frequency accuranc. (<0.1%) |
| • High voltage accurancy. (less than ±1%) |
| • Wide output frequency range. (5~1,000Hz available) |
| • Wide voltage range. (Input range ±20%,output range 0-1000V) |
| • Quick response. (<2ms) |
| • DSP digital control,low waveform distortion. (<2%) |
| • APF check,high power factor |
| • Imported IGBT modul of better performance than SCR. |
| • IGBT/PWM type,light and low noise |
| • High interfere resistance. (Isolated output) |
| • Able to stand 3 phase unbalanced load. |
2) Technical Data:
| Type | 13 (single phase input,three phase output) 33 (three phase input,three phase output) |
| Input Voltage | 380V±20% |
| Frequency | 47~63 Hz |
| Output Voltage | 0~520V adjustable |
| Output frequency | 41~73Hz (5~1000Hz specially made) |
| Modulation mode | IGBT/SPWM |
| Frequency stablity | <0.1% |
| Output voltage stablity | <±1% |
| THD | <2% |
| Response time | 2 ms |
| Overload ability | 120% load 1h,150% load 1min,200% load 20 sec. |
| Phase shift | <±(1~4)% |
| 3 phase balance | automatically |
3) Specification:
Single phase input and Three phase output
| Model | Rated Capacity (KVA) | Rated current (A) High voltage Low voltage | Size LxWxH (mm) |
| CFP13045 | 45 | 68 136 | 780x650x1350 |
Three phase input and Three phase output
| Model | Rated Capacity (KVA) | Rated current (A) High voltage Low voltage | Size LxWxH (mm) |
| CFP33045 | 45 | 68 136 | 780x650x1350 |
4) Picture:
5) Cases:
Provided to CASIC,CSIS,also exported to Japan.
6) Certifications:
7) Test Instruments:
