Home > Products > Variable Frequency Power Suppy CFP > CFP series Triple phase Input &Triple phase Output 20KVA frequency conversion power
CFP series Triple phase Input &Triple phase Output 20KVA frequency conversion power
- 100 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
CFP series Triple phase Input &Triple phase Output 10KVA frequency conversion power
-
CFP series Triple phase Input &Triple phase Output 6KVA frequency conversion power
-
CFP series Triple phase Input &Triple phase Output 3KVA frequency conversion power
-
CFP series Single phase Input &Triple phase Output 15KVA frequency conversion power
-
CFP series Single phase Input &Triple phase Output 10KVA frequency conversion power
-
CFP series Single phase Input &Triple phase Output 6KVA frequency conversion power
Product Details
Place of Origin | Shanghai, China | Brand Name | Nooyi | |
Model Number | CFP33020 | Output Power | Other | |
Output Type | Triple | Size | 460*650*1200mm, 460*650*1200mm | |
Weight | 260KG, 260KG | Input Voltage | 380V±20% | |
Output Voltage | 0-520V adjustable | Type | Other | |
Output Frequency | 41-73Hz adjustable, 50/60/400Hz fixed | Output Current | High:30A Low:60A |
Product Description
CFP series variable frequency power supply
Product Name | Variable Frequency Power Supply | ||
Model | CFP33020 | ||
Power | 20KVA | ||
Mode | IGBT/SPWM Modulation | ||
Input
| Voltage | 3Φ4W+G 380V±15% | |
Frequency | 40-70HZ | ||
Output
| Wave | Sine Wave
| |
Voltage | High:1Φ2W+G 0-300V | Low:1Φ2W+G 0-150V | |
current
| High: 30A | Low: 60A | |
Frequency | 50HZ,60HZ Fixed,43HZ-73HZ Adjustable | ||
Frequency accuracy | ≤0.1% | ||
Response time (Input) | 2mS | ||
voltage supplv stability | ≤1% | ||
Load voltage stability | ≤1% | ||
Total harmonic distortion | ≤2%(Linear load) | ||
Display diagnostic system
| Data display | Voltage, current, frequency, power
| |
Data analys | Voltage 0.1V; Current 0.1A; Power 0.1KW | ||
Fault diagnosis &display
| Overload short circuit,IGBT Module,Fuse,High temperature | ||
Screen | LCD(128*64) | ||
Cooling
| Forced fan
| ||
Working Conditions
| Ambient temperature-10~45℃,Relative humidity0~90% | ||
Size (width * depth * high)
| About 460*650*1200mm | ||
weight
| About 260kg |
IT :Quanta Computer, Foxconn, Maintek Computer, HuaLu Group.
Air conditioning industry : Haier, Gree, ChunLan, Midea, Daikin, Hitachi.
Laser machine Machine tool :Harding, DMG, MAZAK, OR, Jiayou, Daewoo, Trumpf, Bystronic, Mitsubishi, Farley, laserlab, Rofin.
Aerospace Industry :No.3 Institution of CASIC, No.8 Institution of CASIC, Shanghai Aerospace Bureau, No.64 Instition of CASIC, No.610 Instition of CASIC.
Shipbuilding Industry: No704&708 Institute of CSIS. No.1 Machinery Company Kunming Shipbuilding Equipment CO.,Ltd.
Automotive Industry:SAIC, CHERY, BYD, DENSO(China), DENSO(Nansha Guangzhou).
Communication Industry: USA MTN, CHINA TELECOM, CHINA MOBILE, HUAWEI, ZTE.
Scientific Research Institutions: Fudan University, Tongji University, HUST, XMU, LZU.
Medical Industry: HITACHI, SIEMENS, PHILIPS, TOSHIBA, GE ,NEUSOFT.
Steel Industry:Baosteel, HBIS Group, JISCO, Shagang, WISCO.
Export:Japan, Korea, Singapore, Taiwan, Vietnam, Russia, Pakistan, Cuba, India, Nigeria, South Africa.
u Product warranty 18 months,life-long maintenance (except abnormal use)
u Goods to the user side, the company in accordance with the specific circumstances of the project, can provide commissioning services, to ensure the normal operation of the equipment as scheduled.
u Conduct occasional telephone and on-site visits, timely understanding of the operation of the equipment, to solve the problem for the user.
u 24 hours service hotline:400 880 1168
