Stationary Scissor Hydraulic Work Platform/lift
- Qingdao/Dalian/Shanghai/Gangzhou
- T/T
You May Like
-
Stationary Scissor Hydraulic Work Lift/platform
-
25m High Quality Hydraulic Telescopic Cylinder Double Ladder Lift Platform GTTY-25B
-
23m High Quality Hydraulic Telescopic Cylinder Double Ladder Lift Platform GTTY-23B
-
22m High Quality Hydraulic Telescopic Cylinder Double Ladder Lift Platform GTTY-22B
-
22m High Quality Hydraulic Telescopic Cylinder Tilting Ladder Lift Platform GTTY-22
-
24m High Quality Hydraulic Telescopic Cylinder Tilting Ladder Lift Platform GTTY-24
Product Details
| Place of Origin | Shandong, China | Brand Name | Jinchuan | |
| Model Number | SJG5-3 | Lift Mechanism | Scissor Lift | |
| Lift Drive / Actuation | Hydraulic | Power | 5.0kw | |
| Rated Loading Capacity | 5000kg | Min. Lifting Height | 1.5m | |
| Max. Lifting Height | 3.0m | Table Size | 2.0*2.0m | |
| Overall Dimensions | 2.0*2.0*1.2m | Weight | 1000kg |
Product Description
Specifications
1. lifting height:3m2. capacity:5000kg
3. CE&ISO
4. Security and practicability
1. You can control the unit up and down both on the platform and the ground, just need press stop button, it can stop at any point you want.
2. Types of control mode: manual, electrical,diesel. we can also install the remote control device according to your requirement.
3. Power supply:local power is available at the working sites(110V,220V,380V)
Wide variety of capacity :150kg---30T Lifting height :4m-18m
4. In special circumstance, the machine will use explosion-proof electric equipment
5. The platform equipped with antiskid plate to prevent slipping, it is enough safe when it works.
6. The work table would equipped the guardrail to guarantee the safety.
7.The lift has hydraulic overload protective organization to ensure that equipment will not lift when the load beyond its rated load capacity.
8. The machine equipped single control solenoid valves to prevent the platform dropping if power failure. You can open the manual dropped valve to lower the platform to the home position.
We also supply spare parts and supply technical supporting all the time.(Spare parts: control button, travel switch, Oil cylinder seals and the wrench)
