conveyor belt curing press
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Eenor |
Product Description
Specifications
he type: curing press.1. drum vulcanizing press passed the ISO9001.
2. the machine guarantee period is one year.
Good quality with reasonable price. Easy operation with convenient maintenance. Low labor intensity and low energy consumption.
conveyor belt automatic hydraulic vulcanizing curing press / whole conveyor belt production line
Vulcanizing press the ordinary rubber vulcanization used in belt conveyor, nylon rope belt conveyor, PVG/fabric such as core parallel tape. Host for frame structure, the hot plate and piston are using high quality materials and the processing precision, easy wear and corrosion, convenient maintenance, working pressure stability, convenient adjustment.
Model | XLB-1100*5700 | XLB-1400*5700 | XLB-1400*10000 | XLB-1600*8500 | XLB-1600*10000 | XLB-2000*10000 |
Plate size | 1100*5700 | 1400*5700 | 1400*10000 | 1600*8500 | 1600*10000 | 2000*10000 |
Total pressure | 17.55MN | 25.00MN | 49.00MN | 47.60MN | 56.00MN | 70.00MN |
Plate pressure | 2.8 Mpa | 3.13 Mpa | 3.5 Mpa | 3.5 Mpa | 3.5 Mpa | 3.5 Mpa |
Diameter of piston | 500 mm | 360 mm | 450 mm | 500 mm | 450 mm | 600 mm |
Piston number | 5 | 10 | 20 | 14 | 18 | 16 |
Piston stroke | 520 mm | 400 mm | 300 mm | 300 mm | 400 mm | 300 mm |
Working layer | 2 | 2 | 1 | 1 | 2 | 1 |
Clamping force | 0.50 | 0.72 | 0.90 | 0.6 | 1.20 | 1.20 |
Drawing force | 0.40 | 0.60 | 0.80 | 0.5 | 1.10 | 1.00 |
Steam pressure | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa |
Cooling pressure | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa |
Operation system | PLC | PLC | PLC | PLC | PLC | PLC |
Application | nylon rope belt conveyor, PVG/fabric such as core parallel tape. | |||||
This unit is applied to manufacturing of transmission rubber belt, conveyer rubber belt, slab rubber and special rubber products.
This unit consists of principal machine, hydraulic control system and electric control system, etc. parts.
| Contact | Mr. Gavin Ding Mobile: 0086 13583283100 |
Factory Name Address& Product | Qingdao Eenor Rubber Machinery Co., Ltd. Binhai Industrial Zone, Jiaonan, Qingdao, China
We manufacture and export reclaimed rubber machine, tire recycling rubber powder production line, hydrulic vulcanizing press, rubber extruder, rubber strainer, rubber refiner, rubber tile vulcanizing press, rubber mat machine, conveyor belt production line, conveyor belt jointing press, V belt production line, rotary curing press, rubber kneader, rubber calender, rubber cooling machine, rubber hose production line and other rubber machinery. |
Skype, MSN, G-talk&Email | Skype: dingqinpeng MSN: dingqp <at> G-talk: dingqinpeng <at> Email: sales27 <at> |
Our motto: The honesty is the root, a promise is a promise.
