vacuum brazed core bit for concrete
- 200 Set / Sets per Month
- ShangHai/ NingBo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | KAISHANFU/ OEM | |
| Model Number | JC-B-D | Type | Core Drill Bit | |
| Material | Diamond | Use | Other, Well Drilling, For concrete |
Product Description
Specifications
Diamond core drill bits for reinforced concrete:
1.For dry drilling cured concrete,reinforced concrete and asphalt
Different diamond core drill bits for your reference:
Diamond core drill bits for reinforced concrete:
1. Designed for Drilling cured concrete, reinforced concrete with steel
bars and asphalt.
2. Customized available
Specifications:
Item No. | Diameter(mm) | Segement | Effective drilling depth | |||
Segment No. | Segment Height | |||||
Laser | Brazed | |||||
JC-B-D-32A | 22 | 2 | 9 | 7 | 250mm | 300mm |
JC-B-D-32A | 28 | 3 | 9 | 7 | 250mm | 300mm |
JC-B-D-32A | 32 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-38A | 38 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-42A | 42 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-47A | 47 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-52A | 52 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-57A | 57 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-65A | 65 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-78A | 78 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-82A | 82 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-87A | 87 | 4 | 9 | 7 | 150mm | 250mm |
JC-B-D-92A | 92 | 5 | 9 | 7 | 150mm | 250mm |
JC-B-D-102A | 102 | 5 | 9 | 7 | 150mm | 250mm |
JC-B-D-107A | 107 | 6 | 9 | 7 | 150mm | 250mm |
JC-B-D-112A | 112 | 6 | 9 | 7 | 150mm | 250mm |
JC-B-D-117A | 117 | 7 | 9 | 7 | 150mm | 250mm |
JC-B-D-122A | 122 | 7 | 9 | 7 | 150mm | 250mm |
JC-B-D-127A | 127 | 8 | 9 | 7 | 150mm | 250mm |
JC-B-D-132A | 132 | 8 | 9 |
| 150mm | 250mm |
JC-B-D-142A | 142 | 8 | 9 |
| 150mm | 250mm |
JC-B-D-152A | 152 | 10 | 9 |
| 150mm | 250mm |
position close to the Huning Expressway (Between Shanghai and Nanjing). Since its
establishment in 2001, it has been devoted to the research and production of diamond
tools. As a hi-tech enterprise, it passed the ISO9001:2000 Quality Certification early in 2004.
Welcome to our company!!!
Our Factory(Buy from us directly helps you to save your money):
If you have any further questions, just feel
free to contact us. We will be always at
your service!!!
