High Strength Fiber Braided Air Conditioning Flexible Hose for Aftermarket Use
- Shanghai/Ningbo
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Passion Air Conditioning tube, Passion | |
| Model Number | R134A |
Product Description
high strength fiber braided air conditioning flexible hose for aftermarket use
Application scope: Air Conditioning Tube, which is also
called refrigerant pipe, is used in automotive cooling, air-conditioning systems, industrial air conditioners filling and refrigerant conveying.
The hoses can maximize the prevention of refrigerants because the layer in them has high and high anti-leakage effect. They are suitable for all refrigerants, including R12, R22, R502, R401 and R134a. They meet high standard requirement and they are the most ideal substitute goods to imported rubber hose.
Technical standards: SAE J2064.
Appearance: Smooth surface, red, blue and yellow.
| Size | Inside Diameter | Outside Diameter | Working Pressure | Burst Pressure | Band Radius | Weight |
| Inch | mm | mm | Max. Mpa | Min. Mpa | Min. mm | g/m |
| 5/16 | 8.2±0.4 | 15.2±0.5 | 3.5 | 28 | 55 | 146 |
| 13/32 | 10.2±0.4 | 17.2±0.5 | 3.5 | 22 | 65 | 172 |
| 7/16 | 11.5±0.4 | 18.4±0.5 | 3.5 | 23 | 70 | 196 |
| 1/2 | 13.2±0.4 | 20.8±0.5 | 3.5 | 20 | 75 | 231 |
| 5/8 | 15.5±0.4 | 22.8±0.5 | 2.0 | 18 | 85 | 257 |
| 3/4 | 18.5±0.4 | 27.5±0.5 | 1.5 | 18 | 100 | 367 |
PASSION manufacture air conditioning hoses for many types of vehicles, including agricultural, bus and truck markets. With each of our air conditioning hoses conforming to SAE J2064, we are the name you can trust.
Flexible in our approach, whether you require a standard end termination or a hose manufactured to your specific requirements.
Use our air conditioning hoses for:
• Transport industry
• Commercial vehicles
• Agricultural vehicles
• Earth moving equipment
• Mobile refrigeration vehicles
• Conform to SAE J2064.
• Standard end termination available
• Manufactured to your specific requirements if required


Alice and customers
Alice entered "PAISHUN" in 2007, From 2007-2010, Alice worked as a Sales Woman.
She always focus on "How to help customers to solve problems?".
You may find she is very busy sometimes, because she is responsible for loading products, she is checking the ready products, she is attending the Exhibition or she is talking to customers. :-)
From 2010, Alice worked as a Sales Supervisor, she has her team, this is to better serve customers.
Below is her contact information:
Alice J
Sales Supervisor
Tel: +86-571-81023091
Mobile: +86-15968806735
Skype: paishun_ocean
Need the latest price? Please send message to Alice.
I will reply you immdiately.:-)
Have a nice day!
