aluminum silicate ceramic fiber blanket

FOB Price

Negotiable / Piece

100 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

ceramic fiber blanket
1.Resistance to high temperature
2.Low thermal conductivity
3.Density:128kg/m3
5.ceramic fiber plan

Technical Index

Classification Temperature	1050	1260			1400
Code	TXTX-112	TXTX-212	TXTX-312		TXTX-422	TXTX-512
Shrinkage on Heating (%)	950°C ×24h ≤-3	1000°C ×24h ≤-3	1100°C ×24h ≤-3		1200°C ×24h ≤-3	1350°C ×24h ≤-3
Theoretical Thermal Conductivity (W/m·k) (128kg/m3)	0.09 (400°C) 0.176 (800°C)	0.09 (400°C) 0.176 (800°C)	0.09 (400°C) 0.176 (800°C) 0.22 (1000°C)		0.132 (600°C) 0.22 (1000°C)	0.76 (600°C) 0.22 (1000°C)
Theoretical Density (kg/m3)	64/96/128
Specification (mm)	7200/5000/3600/3000×610/1220×/20/30/40/50 According to your requirements
Tensile Strength (Mpa)(128kg/m3)	0.08-0.12
AL2O3(%)	≥44	≥45		≥45	52~55	38~40
ZrO2	-					15~17
AL2O3+SiO2(%)	≥96	≥97	≥99		≥99	—
AL2O3+SiO2+ZrO2(%)	—	—	—		—	≥99
Fe2O3(%)	≤1.2	≤1.0	≤0.2		≤0.2	≤0.2
K2O+Na2O(%)	≤0.5	≤0.5	≤0.2		≤0.2	≤0.2
Package	Plastic Bag Inside, Carton Box Outside
Quality Control System	ISO9001-2000, ISO14001-1996

Characteristic

1.Excellent Chemical Stability

2.Excellent Thermal Stability

3.Excellent Tensile Strength

4.Low Thermal Conductivity

5.Low Heat Storage

Application

1.The material of wall lining and back lining of industrial furnace and the sealing

and insulation material of expanded gaps of furnace wall, furnace door, furnace top lid, etc.

2.Insulating material of high temperature

3.Excellent materials to produce module and folded module
