Product Details
| Place of Origin | Shandong, China | Application | Refractory | |
| Thickness | 0.5-7mm | Width | 610/1220mm | |
| Length | 8-90mtr | Grade | HA (High Aluminum) | |
| Chemical Composition | Al2O3 45-46% SiO2 51-52% | Working Temperature | 1100℃ | |
| Fiber Diameter | 3μm | Thermal Conductivity | 0.075-0.085w/m.k | |
| Shrinkage (1800℉, 3h) | ≤-3% | Brand Name | Yao Xing | |
| Model Number | YXTX-236 |
Product Description
Specifications
Ceramic Fiber Paper1.Density: 200-220kg/m3
2.Thickness: 0.5~7mm
3.Type: High Aluminum
Description
Zibo Yaoxing is a professional manufacturer of ceramic fiber products for more than 10 years.
Ceramic Fiber Paper is made from ceramic fibers bonded with a low percentage of organic binder;
it has excellent thermal insulation properties and good handling characteristics.
Product Characteristic:
♦Low Heat Storage
♦Low Thermal Conductivity
♦Excellent Thermal Electrical Insulation
♦Excellent Machine-processed Capability
♦Excellent Broken Resistance
♦Excellent Flexibility
♦Low Shot Content
Application Range:
♦Industrial insulating ,sealing and protecting materials
♦Electric and thermal insulation materials for electric industry
♦Insulation materials for instrument-equipment
♦Insulating materials for motor industry
♦Filling materials for expansion slot
♦Insulating materials as the sinter resistance
♦Sealing gasket for molten metal
♦Fireproof materials
Classification Temperature | 1260 | 1400 | |
Name | ST Ceramic Fiber Paper | HZ Ceramic Fiber Paper | |
Code | YXTX-236 | YXTX-336 | |
Shrinkage on Heating (%) | 1000°C×24h ≤-3 | 1350°C×24h≤-3 | |
Theoretical Thermal Conductivity (W/m·k) | (200°Caverage) (400°Caverage) (600°Caverage) | 0.075-0.085 0.110-0.121 0.160-0.170 | |
Organic Content (%) | ≤ 10 | ≤ 8 | |
Theoretical Density (kg/m3) | 200±15 | ||
Tensile Strength (Mpa) | ≥0.3 | ≥0.2 | |
Moisture Content(%) | ≤1 | ||
Specification (mm) | 100000/12000×610/1220×0.5/7, According to your requirements | ||
Package | Plastic Bag Inside, Carton Box Outside | ||
Quality Control System | ISO9001-2000, ISO14001-1996 | ||
The package of heat insulation ceramic wool paper: cartons or cartons with pallet.
Also can according your demand to custom.
