ISO9001 Certificate Gas Fireplace Large Volume Blower Fan
- Shanghai
- T/T D/P D/A Credit Card
You May Like
Product Details
| Electric Current Type | AC | Blade Material | Other, Steel Plate | |
| Mounting | Free Standing | Place of Origin | Jiangsu, China | |
| Brand Name | JN | Model Number | G4-73-14D | |
| Power | 37-315 KW | Voltage | 380V/440V/3KV/6KV | |
| Air Volume | 43591-166100 CMH | Speed | m | |
| Certification | CCC, Other | After-sales Service Provided | No overseas service provided |
Product Description
ISO9001 certificate gas fireplace large volume blower fan
Y4-73 and G4-73 are used in the thermal power plant’s ventilation and blower equipment whose steam boiler is small than 670t/h. If there is no other special requirement, G4-73 can also be used in mine ventilation and general ventilation. The medium that the ventilation fan transport is air, the temperature must not exceed 80°C. The medium that the blower fan transport is gas the temperature must not exceed 250°C. A dust-removal device is required in front of the draft fan.
Parameter of G4-73 centrifugal fan
Machine No. |
Motor Power Kw |
Rotation Speed r/min |
Volume Flow |
Pressure |
8D | 18.5 | 1450 | 16156-30993 | 2104-1400 |
9D | 30 | 1450 | 23003-32079 | 2668-2559 |
37 | 35052-44128 | 2440-1775 | ||
11 | 960 | 15229-29216 | 1163-775 | |
10D | 55 | 1450 | 31554-60533 | 3301-2194 |
15 | 960 | 20891-29134 | 1437-1379 | |
18.5 | 31834-40077 | 1315-958 | ||
7.5 | 730 | 15886-30475 | 829-553 | |
11D | 75 | 1450 | 41999-47427 | 4003-3986 |
90 | 53142-80570 | 3943-2659 | ||
22 | 960 | 27806-31400 | 1741-1734 | |
30 | 35183-53343 | 1715-1160 | ||
11 | 730 | 21144-40562 | 1004-669 | |
12D | 132 | 1450 | 54526-76040 | 4777-4582 |
160 | 83088-104600 | 4366-3171 | ||
37 | 960 | 36100-45677 | 2075-2044 | |
45 | 50344-69253 | 1990-1381 | ||
15 | 730 | 27451-30999 | 1196-1191 | |
18.5 | 34734-52661 | 1178-797 | ||
14D | 280 | 1450 | 86586-120740 | 6541-6272 |
315 | 131940-166100 | 5975-4333 | ||
75 | 960 | 57326-64735 | 2831-2819 | |
90 | 72534-109970 | 2789-1883 | ||
37 | 730 | 43591-66425 | 1630-1491 | |
45 | 72059-83624 | 1391-1086 | ||
16D | 185 | 960 | 85571-164150 | 3709-2465 |
75 | 730 | 65069-124820 | 2133-1420 | |
45 | 580 | 51699-99178 | 1343-895 | |
18D | 280 | 960 | 121830-154160 | 4710-4639 |
310 | 169910-233730 | 4518-3126 | ||
132 | 730 | 92648-177730 | 2705-1800 | |
75 | 580 | 73610-141210 | 1702-1133 |
.
..
Certificate:ISO9001:2008,CE
Our factory and outgoing pictures:
