CNHTC Sinotruck Howo Truck Street Sprinkler / Water Sprinkler for Sale

Truck Brand

SINOTRUK—HOWO

Chassis No

ZZ1257N5847

Driving Type

Left Hand Driving

Dimension(Lx W xH)(unloaded)(mm)

11350×2496×3048

Tank  Volume (mm)(m3)

 25

Water Pump

Type

65QSB-50/110

Rate of flaw

50m3/h

Tank Type

Common type

Thickness

5mm

Front Spray water

Duckbill type

Rear sprinkling

Cylinder type

Water cannon

With

Working platform

With

Water absorption pipe(Inner steel )

3” 3 meters

Approaching angle/Departure angle(°)

13.5/11.5

Overhang(front/rear) (mm)

1500/2445

Wheel base (mm)

5800+1350

Max speed(km/h)

75

Curb weight(kg)

12400

Loading Weight(kg)

12450

Actual load (kg)

20000

Engine

Model

WD615.87

Fuel type

Diesel

Power, max(kw/rpm)

290HP

Emission

EURO II

Fuel tanker capacity (L)

350

Transmission

Model

HW19710

10 forward&2 reverse

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Steering system

Model

ZF8098

hydraulic steering with power assistance

Front axle

HF7

Loading capacity:7000kg

Rear axle

MCY13Q

Loading capacity: 13000kg

Tyre

295/80R22.5 tubeless tire

10+1 spare

Electrical system

Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Cab

HOWO76 cab, all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers.
