solar tunnel dryer project technical details

1. Sintering bricks are produced by using clays as raw materials and adopting two-time setting and baking processes, that is Semi-stiff Plastic Extruding Process;

 Drying in the Tunnel Drying Chamber Process and Baking in the Tunnel Kiln Process.

2. Main equipment has box feeder, primary roller crusher, fine pulverizing grinder, double shaft mixer, reversible belt conveyor, multi-buckets excavator, mixing and extruder, double stage vacuum extruding machine, tunnel dryer, tunnel kiln.

3. Tunnel kiln adopt large section with inner width of 3.4 meter, it is designed as a flat ceiling structure with refractory bricks.

 Considering bricks can not have black center and patterns, the firing fuel source is major by inner-mixing-coal, outer-casting-coal as replenish, the heat should meet the firing technology requirement.

 This kiln is suitable for firing products with 1600-2600KJ/Kg.

4. Tunnel kiln has smoke-releasing system, recycling system, waste-heat recovery system, cooling system and pressure balancing system.

This kiln has following features: large section, high yield, small section temperature difference, good heat preservation effect.

Meanwhile, the kiln auto-control system is equipped to ensure the baking heat parameters are stable, so the firing quality is guaranteed.

Technological Process

Clay

                     ↓

                       Loader

                     ↓

Box feeder

↓

               Belt conveyor

↓

De-ironing

         ↓

Primary roller crusher

↓

Belt conveyor

↓

Fine pulverizing grinder

↓

    Belt conveyor

↓             Water added

Double shaft mixer

↓

Revertible warehouse Rubber Conveyor

↓

Ageing House

↓

Multi-bucket Excavators

↓

Box Feeder

Adding Water       ↓

                  Mixing Extruder

↓

De-ironing   Belt conveyor

↓       Water Added

       Double-stage Vacuum Extruder

                         ↓                        Waste

               Automatic column cutter

↓

Automatic brick cutter

↓

Green brick distribution conveyor

↓

Manual setting on drying cart

↓

Ferry pusher

↓

Tunnel dryer

↓

Ferry car

↓

Manual unloading from drying cart

↓

Hydraulic Stepper

↓

Manual setting on kiln cart

↓

Carriage return tractor                  Afterheat

↓

Kiln entrance Ferry Cars

↓

Tunnel kiln pusher

↓

Tunnel Kiln

↓

Outlet Pulling Machine

↓

Ferry cart

                                           ↓

Manual unloading from Kiln cart

↓

Finished brick yard
