Home > Products > Single band repeater > DCS Mobile Signal Repeater GSM1800 Signal Booster

DCS Mobile Signal Repeater GSM1800 Signal Booster

FOB Price

Negotiable / Piece

10 Pieces(Min. Order)

Port Shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Lintratek
Model Number	G17D-1

Product Description

Why do you need to buy repeater/booster ?

Unfortunately,there are still no signal in some places,for example:

-Parking lots,tunnels

-Big store

-Car,boats,office building

-House in remote area

What will be changed when using this products??

1 A cheap and immediate solution that would allow them have clear phone calls or higher speed broad band;

2 No more dropped calls! No more poor reception;

3 No more running to the windows or going outside to talk on your mobile phone;

4 Now you can reach everywhere with signal boosters;

How can repeater bring your mobile phone better signal?

Specification shall care about:

Model No		G17D-1
Parameter data		Uplink	Downlink
Frequency Range	GSM	1710~1785 MHz	1805 ~ 1880 MHz
Output Power		10 ±2dBm	17 ±2dBm
Gain		60 ±2 dB	65±2dB
Bandwidth		25M/25M/75M/60M/45/60M
Ripple in Band		GSM≤5dB,DCS≤6dB,WCDMA≤5dB,PCS≤6dB
Spurious Emission	9KHz~1GHz	≤ -36 dBm
	1GHz~12.75GHz	≤ -30 dBm
Intermodulation Products	9KHz~1GHz	≤ -36 dBm
	1GHz~12.75GHz	≤ -30 dBm
VSWR		≤3
MTBF		>50000 hours
Power Supply		AC:100~240V, 50/ 60Hz;DC:5V 1A
Power Comsumption		< 3W
Impedance		50 ohm
Mechanical Specification
RF Connector		N-Female N
Dimensions (DWH )		1409530(mm)
Cooling		Heatsink Convection cooling
Net weight		0.7Kg
Packing size (DWH )		25024065(mm)
Gross weight		1Kg
Installation Type		Wall Installation
Environment Conditions		IP40
Humidity		< 90%
Operating Temperature		-10℃ ~ 55℃

Packaging & Shipping

Our Services

Install:

Shipping

1. UPS / DHL / EMS / HK EMS / FEDEX / HK post / TNT and so on express(door to door)

2. For Air Shipment, Please choose your favorite, shipping method according your detail requirement

3. The shipping discount is different in different seasons and depend different weight, we will choose the cheapest and safest way according your detail quantities

4. Normally, it will take around 3-7days from China to destination country. Please note that some remote place will need 1-3 days more.

Delivery:

1. Sample within 1-2 days

2. Wholesales Orders : 3-5days according various quantities

3. OEM

4.5-10 days after receiving your sample confirmation and payment.

Warranty:

1. 2 years warranty for the products.

2. Please send back the defective goods which are within the warranty period, we will repair them or send you new one for free

3. If it is the sample or only few pcs accessories (the fee is less or around shipping fee) are damaged, please send us some pictures and video about it need to confirm your problem, then we will send you free new goods instead
